Removing blower and heat-sink
assembly
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
WARNING: The heat sink may become hot during normal operation. Allow
sucient time for the heat sink to cool before you touch it.
CAUTION: For maximum cooling of the processor, do not touch the heat
transfer areas on the heat sink. The oils in your skin can reduce the heat
transfer capability of the thermal grease.
GUID-B44A0F8E-5AB1-468A-9753-729EA3C24BD1
Prerequisites
1 Remove the right-side cover.
2 Follow the procedure from step 1 to step 2 in “Removing the power-supply unit”.
GUID-69E0BF9D-8CB9-4A3E-AF56-77DADF960557
Procedure
1 Remove the screws that secure the blower to the heat-sink assembly.
