Delta 210 Series User Manual

Spout Installation
Insert light pipe (1) into the small hole
in gasket (2), as shown. Ensure the
light pipe is properly seated (3) within
the gasket.
Slide the remaining tubes through
the base. Make sure the sensor light
(1) is facing front, by positioning the
light pipe header (2) inside the body
orientation slot (3). Insert tube (4), up
to the red line marked on the tube,
into red collet (5). After inserting pull
up to engage.
