FOREWORD
Delta Model 36-441B 10" Contractor’s Saws are designed to give high quality performance with maximum depth of
cut capacity up to 3-1/8" at 90° and 2-1/8" at 45°. These Delta Models come equipped with basic machine, sturdy
steel stand, integral dust chute, patented Auto-Set T-Slot miter gage, heavy duty motor, large on/off paddle switch,
extension wing, cast table, convenient up-front blade raising and tilting controls, and 10" blade.
A RIP FENCE ASSEMBLY IS NOT PACKAGED WITH THIS PRODUCT. YOU MUST INSTALL AND
USE A RIP FENCE SYSTEM FOR RIPPING OPERATIONS.
FUNCTIONAL DESCRIPTION
UNPACKING AND CLEANING
Carefully unpack the machine and all loose items from the shipping container(s). Remove the protective coating from
all unpainted surfaces. This coating may be removed with a soft cloth moistened with kerosene (do not use acetone,
gasoline or lacquer thinner for this purpose). After cleaning, cover the unpainted surfaces with a good quality household
floor paste wax. Fig. 2, illustrates the components of the saw. Fig. 3, illustrates the components of the saw stand.
NOTICE: THE PHOTO ON THE MANUAL COVER ILLUSTRATES THE
CURRENT PRODUCTION MODEL. ALL OTHER ILLUSTRATIONS CONTAINED
IN THE MANUAL ARE REPRESENTATIVE ONLY AND MAY NOT DEPICT THE
ACTUAL COLOR, LABELING OR ACCESSORIES AND ARE INTENDED TO
ILLUSTRATE TECHNIQUE ONLY.
