UNPACKING AND CLEANING
Carefully unpack the tool and all loose items from the shipping container(s). Remove the protective coating from all
unpainted surfaces. This coating may be removed with a soft cloth moistened with kerosene (do not use acetone, gasoline
or lacquer thinner for this purpose). After cleaning, cover the unpainted surfaces with a good quality household floor paste
wax.
1. Motor and blower assembly
2. Base
3. Wheel casters (4)
4. Side support (2)
5. Upper bag (bag with loop see Fig. 14)
6. Lower bag
7. Filter bag clamp (2)
8. Firm board
9. Filter bag hanger
10. Hose
11. Hose clamp (2)
12. 5/16 Hex nut (9)
13. 5/16 Lockwasher (12)
14. 5/16-18x3/4" Hex head screw (12)
15. Intake cap
1
2
3
4
5 6
7
8
9
10
11
12
13
14
15
