Delta DJ-20 Series User Manual

9
Fig. 3
1. Stand, Motor, and Electricals
2. Belt
3. Cutterhead Pulley/Belt Guard
4. Push Blocks (2)
5. 1/4-20x5/8" Hex Head Screw (2)
1
2
3
4
5
6
7
8
9
6. 1/4" Flat Washer (2)
7. 1/4-20 Hex Nut (2)
8. #10-16x1/2” Hex Head Screw (4)
9. Dust chute
ASSEMBLY
ASSEMBLY TOOLS REQUIRED
* 4mm hex head wrench (supplied)
* 6 and 8 mm hex head wrenches (not supplied)
* Phillips head screwdriver (not supplied)
* 12 mm wrench for motor bolts (not supplied)
ASSEMBLY TIME ESTIMATE
Assembly time will take about two hours.
