Delta IN2ITION 58470 Series User Manual

3 86517 Rev. E
Notes / Notas / Notes
Backow Protection System
Your Delta
®
faucet hand shower incorporates a backow protection system that has been tested to be in compliance with ASME A112.18.3 and ASME A112.18.1 / CSA B125.1.
It incorporates two certied check valves in series, which operate independently and are integral, non-serviceable parts of the wand assembly.
Sistema de protección de contraujo
Su regadera de mano Delta
®
incorpora un sistema de protección de contraujo que ha sido probado para cumplir con ASME A112.18.3 y ASME A112.18.1 / CSA B125.1.
Incorpora dos válvulas de retención certicadas en serie, que funcionan independientemente y son partes integrales y no reparables del ensamble del mango de la manija.
Système anti-siphonnage
Votre douche à main Delta
®
Faucet est munie d’un système anti-siphonnage dont la conformité aux normes ASME A112.18.3 et ASME A112.18.1/CSA B125.1 a été conrmée
par des tests. Elle comporte deux clapets de non-retour montés en série qui fonctionnent indépendamment. Ces clapets font partie intégrante de la poignée et ils ne sont pas
réparables.
Cleaning and Care
Care should be given to the cleaning of this product. Although its finish is extremely durable, it can be damaged by harsh abrasives or polish. To clean,
simply wipe gently with a damp cloth and blot dry with a soft towel.
Limpieza y Cuidado de su Llave
Tenga cuidado al limpiar este producto. Aunque su acabado es sumamente durable, puede ser afectado por agentes de limpieza o para pulir abrasivos.
Para limpiar su llave, simplemente frótela con un trapo húmedo y luego séquela con una toalla suave.
Instructions de nettoyage
Il faut le nettoyer avec soin. Même si son fini est extrêmement durable, il peut être abîmé par des produits fortement abrasifs ou des produits de
polissage. Il faut simplement le frotter doucement avec un chiffon humide et le sécher à l’aide d’un chiffon doux.

Delta IN2ITION 58470 Series Specifications

General

Flow Rate	1.75 GPM
Finish	Chrome
Hose Length	60 inches
Material	Plastic
Series	58470
Category	Plumbing Product
WaterSense Certified	Yes
Hand Shower Included	Yes
Installation Type	Wall Mounted
Warranty	Limited Lifetime
Spray Patterns	Full Body, Fast Massage, Full Spray with Massage, Massaging, Pause
Type	Handheld
Technology	IN2ITION
Showerhead Type	Dual Showerhead

Summary

Shower Head Installation and Usage

Required Parts for Installation

Lists items like shower arm and flange that may be needed and are sold separately.

Connecting the Shower Head

Instructions on how to attach the shower head to the shower arm, including gasket placement.

Flow Restrictor Notice

Warning about tampering with the flow restrictor and its impact on warranty and performance.

Connecting the Hose

Steps for connecting the hose to the shower head and hand shower, ensuring gasket placement.

Combining Shower Functions

Attaching Hand Shower to Shower Head

Instructions for combining the two shower components by inserting slots and tabs until they snap together.

Securing Shower Head Connection

Guidance on hand-tightening the shower head to the arm if it moves when detaching the hand shower.

Changing Spray Modes

How to select different spray settings using buttons and knobs for various shower configurations.

Product Information and Maintenance

Backflow Protection System

Details on the integrated backflow protection system and its compliance with industry standards.

Cleaning and Care Instructions

Recommendations for cleaning the product gently to maintain its finish and prevent damage.

Delta Faucet Limited Warranty

Warranty Coverage for Parts and Finish

Details on what is covered under the limited warranty for parts and finishes of Delta faucets.

Limitations on Damages

Explanations of limitations regarding special, incidental, or consequential damages for warranty claims.

Additional Consumer Rights

Information about other rights that consumers may have under state or provincial laws.
