Fig. 4
Fig. 4A
1
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
22
23
24
2
20
21
25
26
27
28
29
30
31
32
33
34
35
36
37
8
Fig. 4B
UNPACKING AND CLEANING
WARNING: JOINTER WEIGHT IS APPROXIMATELY 175 LBS. CARE MUST BE TAKEN WHEN LIFTING
JOINTER ONTO STAND. A MINIMUM OF TWO PEOPLE WILL BE REQUIRED TO LIFT THE
MACHINE.Your new jointer is shipped complete in one carton. Carefully unpack the jointer and all loose items. Fig. 4, Fig.
4A and Fig. 4B, illustrate the jointer and all loose items supplied with your machine. Remove the protective coating from the
table surface and all unpainted parts. This coating may be removed with a soft cloth moistened with kerosene (do not use
acetone, gasoline or lacquer thinner for this purpose). After cleaning cover the table surface with a good quality paste wax.
Buff out the wax thoroughly to prevent it from rubbing into the workpieces.
CARTON CONTENTS
