9.2 Technical data
SPECIFICATIONS
Model
M4-TL-US
M5-TL-US
M6-TL-US
M8-TL-US
M10-TL-US
INPUT (DC)
Maximum system voltage
600 V
Nominal voltage
380 V
Maximum operating voltage Voc
540 V
Operating MPPT range
50 V to 480 V
Maximum input current (per MPPT)
12 A
12 A
12 A
12 A
12 A
Maximum short circuit current @ STC
15 A / 15 A
15 A / 15 A
15 A / 15 A / 15 A
15 A / 15 A / 15 A
25 A / 25 A
Maximum DC/AC ratio
1.3
DC disconnect
Integrated
MPP tracker
2
2
3
3
2
Input strings available
2 - 2
2 - 2
2 - 2 - 2
2 - 2 - 2
2 - 2
OUTPUT (AC)
Nominal power @ 240V
3840 W
4800 W
5760 W
7680 W
9600 W
Maximum output power
4000 W
5000 W
6000 W
8000 W
10000 W
Voltage range
183 Vac to 229 Vac @ 208 Vac
211 Vac to 264 Vac @ 240 Vac
Maximum continuous current
16 A
20 A
24 A
32 A
40 A
Nominal frequency
60 Hz
Frequency range
59.3 Hz to 60.5 Hz
Adjustable frequency range
50 Hz to 66 Hz
Night consumption
< 1.5 W
THD @ nominal power
< 3 %
Power factor @ nominal power
> 0.99
Adjustable power factor range
0.85i to 0.85c
Acoustic noise
< 45 dB(A) @ 3 ft (1m)
GENERAL SPECIFICATION
Maximum efficiency
98%
CEC efficiency
97.0 % @ 208 V
97.5 % @ 240 V
97.5 % @ 208 V
97.5 % @ 240 V
97.0 % @ 208 V
97.5 % @ 240 V
97.5 % @ 208 V
97.5 % @ 240 V
97.5 % @ 208 V
97.5 % @ 240 V
Operating temperature range
-22 °F to 149 °F (-30 °C to 65 °C)
de-rating above 113 °F (45 °C )
Storage temperature range
-40 °F to 185 °F (-40 °C to 85 °C)
Humidity
0% to 95%
Maximum operating altitude
9,843 ft (3,000 m)
1) Adjustable value, limited by the output capability of battery pack
2) Adjustable value, Limited by the maximum allowed voltage of battery pack
