14
Standard Specifications
Voltage Class 115V Class 230V Class
Model Number VFD- L A/B
40W 001 40W 001
Weight g (lb) A (standard)
270 (0.60) 440 (0.97) 260 (0.57) 430 (0.95)
Weight g (lb) B (build-in EMI filter)
350 (0.77) 525 (1.16) 340 (0.75) 510 (1.12)
Max. Applicable Motor Output (W) 25/40 60/100 25/40 60/100
Rated Output Capacity (VA) 106/152 212/303 106/152 212/303
Rated Output Current (A) 0.28/0.4 0.56/0.8 0.28/0.4 0.56/0.8
Maximum Output Voltage (V)
Two times proportion to
Input Voltage
Proportional to Input
Voltage
Output Rating
Rated Frequency (Hz) 1.00 to 120.00 Hz
Rated Voltage/Frequency
Single phase
100 to 120 VAC
50/60 Hz
Single phase
200 to 240 VAC 50/60Hz
Voltage/Freq. Tolerance
Voltage: ±10%, Frequency: ±5%
Input Rating
Input Current (A) 1.1A 1.5A 2.2A 3.0A 0.5A 0.7A 1.0A 1.4A
Control Systems
SVPWM (Space Vector Pulse Width Modulation,
carrier frequency 10kHz)
Torque Setting High/Low, Switching
Overload Endurance 150% of rated current for 1 minute
Accel/Decel Time 0.05 to 30.0 seconds
Control
Characteristics
Torque Promotion Torque Boots: 0 or 8%
Frequency Setting Potentiometer
Panel RUN/STOP, FORWARD/REVERSE
Operation Setting
Signal
Ext. Terminal RUN/STOP, FORWARD/REVERSE, RS-485
Panel Fault Indication (LED Flash)
Operation
Characteristics
Output Indiction
Ext. Terminal Fault Indication (Open Collector)
Protection
Self-testing, Over Voltage, Over Current, Under
Voltage, Overload, Overheating, Thermal.
Cooling Natural air-cooling
Installation Location
Altitude 1,000m or lower, keep from corrosive
gasses, liquid and dust
Pollution Degree 2
Ambient Temperature -10
o
C to 40
o
C (Non-Condensing and not frozen)
Storage Temperature -20
o
C to 60
o
C
Ambient Humidity Below 90% RH (non-condensing)
Environment
Vibration
9.80665m/s
2
(1G) less than 20Hz, 5.88m/s
2
(0.6G) at 20 to 50Hz
To Next Page
