19
ADV-M51
PARTS LIST OF EXPLODED VIEW
Ref.No. Part No. Part Name Remarks Q'ty New
1 00D 1U- 3617 MAIN PWB ASS'Y COP11724B For JP
1 00D 1U- 3617 A MAIN PWB ASS'Y COP11724C For E3
1 00D 1U- 3617 B MAIN PWB ASS'Y COP11724D For E2,EK
1-1 AUDIO UNIT 1U-3617-1 for E3,JP 1
1-1 AUDIO UNIT(EK) 1U-3617B-1 for EK,E2 1
1-2 PIN JACK UNIT 1U-3617-2 1
1-3 DISPLAY UNIT 1U-3617-3 1
2 00D 1U- 3528 AMP/POWER PWB ASS'Y (S) COP11722B For JP
2 00D 1U- 3528 A AMP/POWER PWB ASS'Y (E3) COP11722C For E3
2 00D 1U- 3585 AMP/POWER PWB ASS'Y (E2) COP11723B For E2,EK
2-1 AMP/VIDEO UNIT 1U-3528-1 for E3,JP 1
2-1 AMP/VIDEO UNIT 1U-3585-1 for EK,E2 1
2-2 POWER UNIT 1U-3528-2 for E3,JP 1
2-2 POWER UNIT 1U-3585-2 for EK,E2 1
2-3 POSISTOR UNIT 1U-3528-3 for E3,JP 1
2-3 POSISTOR UNIT 1U-3585-3 for EK,E2 1
2-4 SP TERMINAL UNIT 1U-3528-4 for E3,JP 1
2-4 SP TERMINAL UNIT 1U-3585-4 for EK,E2 1
2-5 D-TERMINAL UNIT 1U-3528-5 for JP 1
3 00D 1U3 474A DSP PCB ASS'Y COP1U3474A
4 00D 411 2035 202 CHASSIS , MAIN CUA1A249 1
5 00D 104 0317 011 FOOT CKL1A189 4 *
6 00D 461 1066 015 CUSHION , FOOT KHG1A285 4 *
7 00D 449 0204 001 HOLDER , MECHA(FL) CMH1A235 1
8 00D 449 0205 107 HOLDER , MECHA(FR) CMH1A236 1
9 00D 412 5049 010 EARTH , HOLDER CMC1A230 2 *
10 00D 449 0205 009 HOLDER , MECHA(BL) CMH1A237 1
11 00D 449 0207 105 HOLDER , MECHA(BR) CMH1A238 1
12 00D 412 5049 010 EARTH , HOLDER CMC1A230 2 *
13 00D 412 1945 008 SUPPORT , BOTTON CRE3A060 2
14 00D 412 2741 007 SUPPORT , BOTTON CRE2A060 2
16 00D 009 0236 017 15P CARD CABLE(1.25MM, 90MM) CWC1B2A15B090A 1
17 00D 009 0233 036 25P CARD CABLE (90M/M) CWC1B2A25A090A 1
18 00D 412 2404 069 HOLDER , PWB CRE1A061 1
20 00D 337 0119 107 SINGLE DVD LOADER HJDRL-S871D 1 *
21 00D 204 0575 001 6P WIRE ASS'Y CWZADVM51CX061 1
22 00D 204 2962 007 7P WIRE ASS'Y CWZADVM51CX072 1
23 00D 204 2963 006 WIRE ASS'Y CWZADVM51CX092 1
24 00D 415 0925 219 COVER , MECHA CMX1A158 1 *
25 00D 412 5035 011 BRACKET , PWB CMD1A534 1
26 00D 415 0914 217 SHEET , PC CMX1A161 1
27 00D 412 2741 010 SUPPORT , BUTTON CRE1A060 For E3,E2,EK 4
28 00D 415 0929 118 SHEET , PC(C) CMX1A160 1
29 00D 412 5036 214 STAY , PWB CMH1A233 1
31 00D 105 1460 007 PANEL , BACK CKF1A284Z 1
32 00D 421 0811 001 FAN , MOTOR ASS'Y HDM1604KL04WB30 1
33 00D 443 1583 118 COLLAR CMH1A234 4
34 00D 103 1767 311 COVER , FAN CGP1A021 1
35 00D 461 1165 013 RUBBER , SPACER CHG1A286 1
! 36 00D 206 2089 106 CORD , POWER(EUR) CJA2B043ZA For E2 1
! 36 00D 206 2085 003 POWER CORD CJA2J066Z For JP 1
! 36 00D 206 2160 009 CORD , POWER CJA523FBYA For E3 1
! 36 00D 206 2128 009 CORD , POWER(AC/PSB/5A,250V) HJA2E056Z For EK 1
37 00D 449 0213 005 BUSHING , AC CORD KHR1A028 1 *
38 - HEAT SINK ASS'Y CMY1A235XA For E3 1
38 - HEAT SINK ASS'Y CMY1A235YA For E2,EK 1
38 - HEAT SINK ASS'Y CMY1A235ZA For JP 1
39 00D 412 5033 110 BRACKEEET , HEAT SINK(F) CMD1A532 1
40 00D 412 5034 119 BRACKET , HEAT SINK(B) CMD1A533 1
41 00D 415 0915 119 SHEET , POSISTOR CMX1A159 1
42 00D 009 0233 010 9P CARD CABLE (60M/M) CWC1B2A09A060A 1
Note: The symbols in the column ”Remarks” indicate
the following destinations.
JP : Japan model
E3 : U.S.A. & Canada model
E2 : Europe model
EK : U.K. model
