127
AVR-4806/AVC-A11XV
PARTS LIST OF EXPLODED VIEW
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊
Thepartslistedbelowareformaintenanceonly,mightdifferfromthepartsusedintheunitinappearancesordimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
EU: U.S.A. model EC: Canada model EUT : Taiwan R.O.C.model
E2: Europe model E1C : China model JP: Japan model
Ref. No. Part No. Part Name Remarks Q'ty New
1 00D1U-3356A AMP UNIT ASS'Y for EU,EC,EUT 1
1 00D1U-3356D AMP UNIT ASS'Y for E2,E1C,JP 1
1-1 AMP-L UNIT
1-2 AMP-R UNIT
2 00D1U-3667 DIGITAL UNIT ASS'Y for EU,EC 1 *
2 00D1U-3667A DIGITAL UNIT ASS'Y for E2,E1C,EUT,JP 1 *
3 00D1U-3668 A.VIDEO UNIT ASS'Y 1 *
3-1 S&CVBS UNIT
3-2 V.CONNECT UNIT
4 00D1U-3669 D.VIDEO UNIT ASS'Y
5 00D1U-3670 AUDIO UNIT ASS'Y for EU,EC 1 *
5 00D1U-3670A AUDIO UNIT ASS'Y for E2,E1C,JP 1 *
5 00D1U-3670E AUDIO UNIT ASS'Y for EUT 1 *
5-1 AUDIO UNIT
5-2 ADC/DAC UNIT
6 00D1U-3671 FRONT UNIT ASS'Y for EU,EC 1 *
6 00D1U-3671A FRONT UNIT ASS'Y for E2,E1C,EUT 1 *
6 00D1U-3671D FRONT UNIT ASS'Y for JP 1 *
6-1 FLD UNIT
6-2 P.SW UNIT
6-3 FUNCTION SEL UNIT
6-4 P.LED UNIT
6-5 TACT UNIT
6-6 USER UNIT
6-7 VOL UNIT
6-8 H/P UNIT
6-9 FRONT IN UNIT
6-10 MIC UNIT
6-11 FLD SUPPLY UNIT
6-12 PHONO UNIT
6-13 TRIGGER UNIT
6-14 DIGITAL IN UNIT
6-15 TUNER IN UNIT for E2,E1C,EUT,JP
6-16 D.TERMINAL UNIT for JP
6-17 D.CONNECT UNIT for JP
7 00D1U-3672 PRIMARY UNIT ASS'Y for EU,EC 1 *
7 00D1U-3672A PRIMARY UNIT ASS'Y for E2 1 *
7 00D1U-3672B PRIMARY UNIT ASS'Y for E1C 1 *
7 00D1U-3672D PRIMARY UNIT ASS'Y for JP 1 *
7 00D1U-3672E PRIMARY UNIT ASS'Y for EUT 1 *
7-1 PRIMARY UNIT
7-2 AMP SUPPLY UNIT
7-4 E2 RL UNIT for E2,E1C
7-5 ETHER RL UNIT
7-7 DSP REG UNIT
