Denon AVC-A1SR Service Manual

72
AVR-5803/AVC-A1SR
Ref. No. Part No. Part Name Remarks Q'ty Ref. No. Part No. Part Name Remarks Q'ty
F13 206 1039 089 Fuse 3.15A for EU,EC,EUT 1
F13 206 1015 074 Fuse 3.15A for E2,E1,E1C 1
F14 206 1046 027 Fuse 5A for EU,EC,EUT 1
F14 206 1015 090 Fuse 5A for E2,E1,E1C 1
F15,16 206 1039 089 Fuse 3.15A for EU,EC,EUT 2
F15,16 206 1015 074 Fuse 3.15A for E2,E1,E1C 2
FF201 EP-5870 Fuse holder for EU,EC,EUT 1
FF202 202 0040 909 Fuse clip for E2,E1,E1C 1
FF203 202 0040 909 Fuse clip for EU,EC,E2,E1,EUT 1
FF501-504 202 0040 909 Fuse clip 4
FF506,507 202 0040 909 Fuse clip 2
FH201 EP-5870 Fuse holder for EU,EC,EUT 1
FH202 202 0040 909 Fuse clip for E2,E1,E1C 1
FH203 202 0040 909 Fuse clip for EU,EC,E2,E1,EUT 1
FH501-504 202 0040 909 Fuse clip 4
FH506,507 202 0040 909 Fuse clip 2
L101,102 235 0060 918 Inductor 4.7uH 2
RL201,202 214 0221 006 Relay (TV-8) 2
T101 233 6408 002 Sub trans (583E3) for EU,EC,EUT 1
T101 233 6411 002 Sub trans (A1SRE1E2) for E2,E1 1
T101 233 6414 009 Sub trans (A1SRE1C) for E1C 1
T201 233 6410 003 Mini trans. (583E3) for EU,EC,EUT 1
T201 233 6420 006 Mini trans. (A1SRE1E2) for E2,E1 1
T201 233 6421 005 Mini trans. (A1SRE1C) for E1C 1
W203,204 205 1034 023 M3 Screw terminal 2
415 0299 000 Condenser cover (for C209) for E2,E1,E1C 1
513 3730 080 Fuse label (T6.3AL), for F1 for E2,E1,E1C 1
513 3730 048 Fuse label (T2.5AL), for F8 for E2,E1 1
513 2654 086 Fuse label (5A/125V), for F11,12 for EU,EC,EUT 2
513 3730 077 Fuse label (T5AL), for F11,12,14 for E2,E1,E1C 3
513 3730 051 Fuse label (T3.15AL), for F13,15,16 for E2,E1,E1C 3
OTHER PARTS GROUP
CN602-607 205 1230 063 6P pin header (6035) 6
CW040 205 0885 082 4P connector socket (TUC-P) 1
CW060 205 0942 019 6P connector socket (TUC-P) 1
CW064 205 0343 061 6P connector base (KR-PH) 1
CW068,069 205 0942 019 6P connector socket (TUC-P) 2
CW083-085 205 0885 095 8P connector socket (TUC-P) 3
CW101 205 0885 053
10P connector socket (TUC-P) 1
CW960 205 0942 019 6P connector socket (TUC-P) 1
CX021 205 1093 006 2P VH connector base
for E2,E1,E1C,EUT 1
CX025 205 0581 001 2P VH connector base for EU,EC,E2,E1,EUT 1
CX027 205 0453 003 2P VH connector base(L) 1
CX028 205 0606 025 2P wrapping terminal 1
CX037 205 0234 031 3P EH SID connector base 1
CX040 205 0884 083 4P connector base (TUC-P) 1
CX053 205 0343 058 5P connector base (KR-PH) 1
CX060 205 0943 018 6P connector base (TUC-P) 1
CX061,062 205 0343 061 6P connector base (KR-PH) 2
CX064 205 0343 061 6P connector base (KR-PH) 1
CX067 205 0343 061 6P connector base (KR-PH) 1
CX068,069 205 0943 018 6P connector base (TUC-P) 2
CX071 205 0943 021 7P connector base (TUC-P) 1
CX073 205 0343 074 7P connector base (KR-PH) 1
CX081-085 205 0884 096 8P connector base (TUC-P) 5
CX101,102 205 0884 054 10P connector base (TUC-P) 2
CX830 205 0278 039 3P EH connector base (BK) 1
CX839 205 0276 031 3P EH connector base (BU) 1
CX930 205 0233 032 3P EH connector base 1
CX931 205 0234 031 3P EH SID connector base 1
CX936 205 0277 030 3P EH connector base (RD) 1
CX937 205 0296 037 3P EH connector base (YW) 1
CX960 205 0943 018 6P connector base (TUC-P) 1
CY027 205 0581 001 2P VH connector base 1
CY030 205 0343 032 3P connector base (KR-PH) 1
CY045 205 0321 041 4P connector base (RED) 1
CY046 205 0343 045 4P connector base (KR-PH) 1
CY053 205 0343 058 5P connector base (KR-PH) 1
CY061 205 0343 061 6P connector base (KR-PH) 1
CY075 205 0343 074 7P connector base (KR-PH) 1
CY143 205 0375 042 14P connector base (KR-PH) 1
CY930 205 0234 031 3P EH SID connector base 1
CY982 205 0343 087 8P connector base (KR-PH) 1
F1 206 1051 009 Fuse 12A for EU,EC,EUT 1
F1 206 1036 011 Fuse 6.3A for E2,E1,E1C 1
F8 206 1046 014 Fuse 8A for EU,EC,EUT 1
F8 206 1015 032 Fuse 2.5A for E2,E1 1
F11,12 206 1046 027 Fuse 5A for EU,EC,EUT 2
F11,12 206 1015 090 Fuse 5A for E2,E1,E1C 2
