AVR-5803/AVC-A1SR
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
CC143,144 257 0504 940 Ceramic chip 33pF/50V CC73CH1H330J
CC147,148 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J
CC149,150 254 4524 985 Electrolytic 10uF/50V
CE04W1H100M (SMG/RE3)
OTHER PARTS GROUP Q'ty
AS101,102 205 0452 017 Style pin 2
AS104 205 0452 017 Style pin 1
AS106 205 0452 017 Style pin 1
CW121 204 6732 000
12P SAN-SAN connector cord
1
CW141 204 6733 009 14P PH-SAN connector cord 1
CX034 205 0406 034 3P connector base (KR-PH) 1
CX041 205 0343 045 4P connector base (KR-PH) 1
CX142,143 205 0375 042 14P connector base (KR-PH) 2
CX154 205 0375 055 15P connector base (KR-PH) 1
CY032 205 0321 038 3P connector base (RED) 1
CY043 205 0343 045 4P connector base (KR-PH) 1
CY072 205 0343 074 7P connector base (KR-PH) 1
CY095 205 0343 090 9P connector base (KR-PH) 1
CY104 205 0375 000 10P connector base (KR-PH) 1
CY122 205 0375 026 12P connector base (KR-PH) 1
CY126 205 0375 026 12P connector base (KR-PH) 1
CY136 205 0375 039 13P connector base (KR-PH) 1
JK101 204 8562 016 2P pin jack (S-GND) 1
JK102 204 8562 016 2P pin jack (S-GND)
for E2,E1,E1C,EUT
1
JK201-203 204 8513 007 6P pin jack (S-GND) 3
JK801 204 8513 007 6P pin jack (S-GND) 1
RL101-111 214 0223 004 Relay (EC2-24N35) 11
RL113-115 214 0223 004 Relay (EC2-24N35) 3
RL601-604 214 0223 004 Relay (EC2-24N35) 4
RL801 214 0223 004 Relay (EC2-24N35) 1
SH101 414 0799 109 Shield plate 1
203 0711 008 1P SIN-SIN wire 1
1U-3437/3437A A&V IN P.W.B. UNIT ASS'Y
SEMICONDUCTORS GROUP
IC102-112 263 1098 900 IC LM833MX
IC201-203 262 2545 006 IC TC9274N-011
IC204 262 2726 003 IC TC9273N-***B
IC205 262 2540 904 IC TC9459F
IC206,207 263 0615 902 IC BA15218F
IC301-303 263 1082 903 IC TK15420MTL
IC304,305 262 2826 903 IC BU4051BCF
IC306 263 1082 903 IC TK15420MTL
IC307 262 2013 907 IC BU4053BCF
IC308 262 2012 908 IC BU4052BCF
IC309 262 2826 903 IC BU4051BCF
IC310 263 1082 903 IC TK15420MTL
IC311 262 2012 908 IC BU4052BCF
IC501 262 2114 903 IC UPD4721GS-GJG
IC502 262 2580 906 IC CXA1511M
TR201 269 0048 904 Transistor DTC143EK
TR203-210 273 0460 905 Transistor KTC2875B
TR301 271 0238 908 Transistor 2SA1037K (S/R)
TR302,303 269 0192 902
Transister KRC102S (10K-10K)
TR501 269 0055 900 Transistor DTA144EK
TR502 269 0082 902 Transistor DTC114EK
TR503 269 0083 901 Transistor DTA114EK
TR904 269 0192 902
Transister KRC102S (10K-10K)
TR905 269 0144 905 Transistor DTC114YK
TR906 271 0310 907 Transistor 2SA1163 (BL)
TR907-911 273 0426 907 Transistor 2SC2412KLN
D201 276 0559 909 Diode DAP202K
D302,303 276 0739 907 Diode KDS181
D904-908 276 0740 909 Diode KDS184
ZD505,506 276 0694 932 Zener diode UDZ6.8B
ZD507 276 0683 956 Zener diode UDZS15B
RESISTORS GROUP
R121-124 247 2012 925 Carbon chip 100kohm 1/16W RM73B--104J
R125,126 247 2005 903 Carbon chip 100ohm 1/16W RM73B--101J
R127,128 247 2004 920 Carbon chip 47ohm 1/16W RM73B--470J
R129,130 247 2011 942 Carbon chip 47kohm 1/16W RM73B--473J
R131-134 247 2012 925 Carbon chip 100kohm 1/16W RM73B--104J
R135,136 247 2005 903 Carbon chip 100ohm 1/16W RM73B--101J
R137,138 247 2004 920 Carbon chip 47ohm 1/16W RM73B--470J
