Denon AVC-A1SR Service Manual

90
AVR-5803/AVC-A1SR
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
R349 247 2007 943 Carbon chip 1kohm 1/16W RM73B--102J
R350 247 2012 925 Carbon chip 100kohm 1/16W RM73B--104J
R351 247 2007 943 Carbon chip 1kohm 1/16W RM73B--102J
R358 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R365-373 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R376 247 2007 943 Carbon chip 1kohm 1/16W RM73B--102J
R379 247 2002 964 Carbon chip 10ohm 1/16W RM73B--100J
R382 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R383 247 2002 964 Carbon chip 10ohm 1/16W RM73B--100J
R397,398 247 2018 903 Carbon chip 0ohm 1/16W RM73B--0R0K
R399 247 2007 943 Carbon chip 1kohm 1/16W RM73B--102J
VR301 211 6132 925 Semi fixed resistor 10ohm V06PB103
VR302 211 6132 983 Semi fixed resistor 100ohm V06PB104
CAPACITORS GROUP
C309,310 254 4306 925 Electrolytic 10uF/50V CE04W1H100M (SRE)
C311,312 257 0508 962 Ceramic chip 750pF/50V CC73CH1H751J
C314 257 0511 904 Ceramic chip 0.01uF/50V CK73F1H103Z
C315 254 4524 943 Electrolytic 1uF/50V CE04W1H010M (SMG/RE3)
C316 257 0509 929 Ceramic chip 1000pF/50V CK73B1H102K
C317 254 4305 984 Electrolytic 2.2uF/50V CE04W1H2R2M (SRE)
C318 254 4524 943 Electrolytic 1uF/50V CE04W1H010M (SMG/RE3)
C319 254 4524 914 Electrolytic 0.22uF/50V CE04W1HR22M (SMG/RE3)
C320 254 4538 913 Electrolytic 22uF/16V CE04W1C220M (SMG/RE3)
C321 256 1058 942 Metallized 0.056uF/50V CF93A1H563J (JL)
C322 254 4538 939 Electrolytic 47uF/16V CE04W1C470M (SMG/RE3)
C323 254 4524 943 Electrolytic 1uF/50V CE04W1H010M (SMG/RE3)
C325 254 3053 910 Electrolytic 22uF/16V CE04D1C220MBP
C328,329 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C330 257 0010 942 Ceramic chip 0.022uF/50V CK73B1H223K
C331 256 1058 939 Metallized 0.047uF/50V CF93A1H473J (JL)
C332 254 4524 985 Electrolytic 10uF/50V CE04W1H100M (SMG/RE3)
C333 254 4524 943 Electrolytic 1uF/50V CE04W1H010M (SMG/RE3)
C334 254 4524 930 Electrolytic 0.47uF/50V CE04W1HR47M (SMG/RE3)
C335-337 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C338 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J
C339 257 0010 942 Ceramic chip 0.022uF/50V CK73B1H223K
C340,341 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C343 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C347 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C348 257 0503 941 Ceramic chip 12pF/50V CC73CH1H120J
C349 254 4524 985 Electrolytic 10uF/50V CE04W1H100M (SMG/RE3)
C350 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C351,352 257 0010 984 Ceramic chip 0.047uF/50V CK73B1H473K
C363 254 4538 913 Electrolytic 22uF/16V CE04W1C220M (SMG/RE3)
C366 257 0011 996 Ceramic chip 0.1uF/25V CK73B1E104K
C369,370 257 0509 929 Ceramic chip 1000pF/50V CK73B1H102K
C387 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C388 254 4538 939 Electrolytic 47uF/16V CE04W1C470M (SMG/RE3)
C390 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C391 254 4524 943 Electrolytic 1uF/50V CE04W1H010M (SMG/RE3)
C392 257 0501 901 Ceramic chip 0.01uF/50V CK73B1H103K
C393 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J
C394,395 257 0503 967 Ceramic chip 15pF/50V CC73CH1H150J
C396 254 4524 943 Electrolytic 1uF/50V
CE04W1H010M (SMG/RE3)
C397 257 0511 904 Ceramic chip 0.01uF/50V CK73F1H103Z
C398 257 0506 951 Ceramic chip 100pF/50V CC73CH1H101J
C400 257 0509 929 Ceramic chip 1000pF/50V CK73B1H102K
OTHER PARTS GROUP Q'ty
CF301 261 0079 005 Ceramic resonator CSB456F11 1
CF302 261 0031 001 Ceramic filter BFU450C4 1
CF303 261 0136 906 Ceramic filter MS2G 1
CF304 261 0135 907 Ceramic filter MA8 1
CF305 261 0116 007 Ceramic filter SFU450B3 1
CY031 205 0343 032 3P connector base (KR-PH) 1
CY111 205 0375 013 11P connector base (KR-PH) 1
JK301 205 0603 015 3P antenna terminal 1
L301 235 0060 905 Inductor 2.2uH 1
L302 235 0060 950 Inductor 10uH 1
LF306 232 9010 009 Antibirdie filter 1
T302 231 2085 009 FM DET trans. 1
T304 231 1138 009 AM IFT 1
T305 231 2096 001 MW ant.-osc. coil 1
XL301 399 0075 003 Crystal 7.2MHz 1
