Denon AVC-X6700H User Manual

.
wq reyt
u
A
Power operation button (X)
Used to turn the power of the MAIN ZONE (room where this unit is
located) on/off (standby). (v p. 98)
B
Power indicator
This is lit as follows according to the power status:
0
Green: Power on
0
Off: Normal standby
0
Red:
0
When “HDMI Pass Through” is set to “On” (v p. 198)
0
When “HDMI Control” is set to “On” (v p. 200)
0
When “Network Control” is set to “Always On” (v p. 256)
C
SOURCE SELECT knob
This selects the input source. (v p. 98)
D
Remote control sensor
This receives signals from the remote control unit. (v p. 9)
E
Display
This displays various pieces of information. (v p. 22)
F
MASTER VOLUME knob
This adjusts the volume level. (v p. 99)
G
Door
When you are using buttons and/or connectors behind the door, press
the bottom of the door to open it. Be careful not to catch your fingers
when closing the door.
.
Contents
Connections Playback Settings Tips Appendix
19
Front panel Display Rear panel Remote Index

Denon AVC-X6700H Specifications

General

Frequency range	10 - 10000 Hz
Output impedance	4 - 16 Ω
Pre-out channels	13.2
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	750 W
Package weight	17400 g
Display	-
HDCP version	2.3
Apple docking	No
Product color	Black
Audio decoders	DTS Virtual:X, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Internet radio services supported	Amazon Music, Deezer, Pandora, Spotify, Tidal, TuneIn
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Headphone outputs	1
Composite video out	2
Number of HDMI outputs	3
HDMI in	8

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	14800 g
