Denon AVC-X6700H User Manual

Accessories
8
Inserting the batteries
9
Operating range of the remote control unit
9
Features
10
High quality sound
10
High performance
13
Easy operation
17
Part names and functions
18
Front panel
18
Display
22
Rear panel
24
Remote control unit
28
Connections
Speaker installation
32
Connecting speakers
41
Before connecting speakers
41
Speaker configuration and “Amp Assign” settings
45
Connecting 5.1-channel speakers
47
Connecting 7.1-channel speakers
48
Connecting 9.1-channel speakers
53
Connecting 11.1-channel speakers
61
Connecting 13.1-channel speakers
65
Bi-amp connection
73
Connecting 9.1-channel speakers: Second pair of front speakers
75
Connecting multi-zone speakers
76
Connecting an external power amplifier
80
Connecting a TV
81
Connection 1 : TV equipped with an HDMI connector and
compatible with the ARC (Audio Return Channel) / eARC
(Enhanced Audio Return Channel)
82
Connection 2 : TV equipped with an HDMI connector and
incompatible with the ARC (Audio Return Channel) / eARC
(Enhanced Audio Return Channel)
83
Connection 3 : TV equipped without an HDMI connector
84
Connecting a playback device
85
Connecting a set-top box (Satellite tuner/cable TV)
86
Connecting a DVD player or Blu-ray Disc player
87
Connecting a player device compatible with the 8K
88
Connecting a video camcorder or game console
89
Connecting a turntable
90
Connecting a USB memory device to the USB port
91
Connecting to a home network (LAN)
92
Wired LAN
92
Wireless LAN
93
Connecting an external control device
94
REMOTE CONTROL jacks
94
TRIGGER OUT jacks
95
Connecting the power cord
96
Contents Connections Playback Settings Tips Appendix
2
Front panel Display Rear panel Remote Index

Denon AVC-X6700H Specifications

General

Frequency range	10 - 10000 Hz
Output impedance	4 - 16 Ω
Pre-out channels	13.2
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	750 W
Package weight	17400 g
Display	-
HDCP version	2.3
Apple docking	No
Product color	Black
Audio decoders	DTS Virtual:X, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Internet radio services supported	Amazon Music, Deezer, Pandora, Spotify, Tidal, TuneIn
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Connectivity technology	Wired & Wireless
Speakers connectivity type	Binding post
Headphone outputs	1
Composite video out	2
Number of HDMI outputs	3
HDMI in	8

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	14800 g
