28
SURROUND MODES AND PARAMETERS
Symbols in the table
S This indicates the audio output channels or surround parameters that can be set.
D This indicates the audio output channels. The output channels depend on the settings of “Speaker Config.”.
Surround mode
Channel output Surround Parameter
Front L/R Center Surround L/R Surround Back L/R Subwoofer Mode
D. Comp z3 DRCz4 LFE z5
DIRECT (2channel)
S D
z2
SS
DIRECT (Multi-channel)
SDD D
z1
DSSS
STEREO
S DSSS
MULTI CH IN
SDD D D S
DOLBY PRO LOGIC gx SDD D DSSS
DOLBY PRO LOGIC g S D D DSSS
DTS NEO:6
SDD D DSSS
DOLBY DIGITAL
SDD D D S S
DOLBY DIGITAL Plus
SDD D D S S
DOLBY TrueHD
SDD D D S
DTS SURROUND
SDD D D S S
DTS 96/24
SDD D D S S
DTS-HD
SDD D D S S
DTS Express
SDD D D S S
MULTI CH STEREO
SDD D D S S
VIRTUAL
S D
z2
SS
z1 A signal for each channel contained in an input signal is output as audio.
z2 Only when “Mode” is set to “LFE+Main”, sound is output from the subwoofer.
z3 This item can be selected when a Dolby Digital or DTS signal is played.
z4 This item can be selected when a Dolby TrueHD signal is played.
z5 This item can be selected when a Dolby Digital or DTS signal or DVD-Audio is played.
