Rear panel
See the page indicated in parentheses ( ).
q
w e
tr
yi uoQ0
q PRE OUT connectors ············································· (C 3, 24, 25)
w Speaker terminals ················································· (C 3, 24, 25)
e DOCK CONTROL jack ································································ (9)
r S-VIDEO connector ··································································· (9)
t VIDEO connectors ································································· (7, 8)
y Power cord ········································································· (C 4)
u Digital audio connectors ······················································· (7, 8)
i HDMI connectors ··························································· (C 4, 5)
o Analog audio connectors ·················································· (7, 8, 9)
Q0 FM/AM antenna terminals ····················································· (10)
NOTE
Do not touch the inner pins of the connectors on the rear panel.
Electrostatic discharge may cause permanent damage to the unit.
