Denon AVR-2312 Service Manual

159
Ref. No. Part No. Part Name Remarks Q'ty New
M10 nsp PANEL REAR E3 CKF1A448Z 1 *
M10 nsp PANEL REAR E2,EA CKF1A448Y 1 *
M10 nsp PANEL REAR E1C CKF1A448X 1 *
M11 00M07BW257010 CABINET TOP BK CKC2A155K117 1
M11 943403002040M TOP CABINET SP CKC2A155D11 1
★
M14 nsp CLAMPER CHR301 10
★
M15 nsp CUSHION EVA CHG1A518 1
★
M16 nsp LABEL HOT CQB1A906Z 1
★
M17 nsp TAPE HEMELON 10mm CHS1A032 1
★
M18 nsp TAPE HEMELON 10mm CHS1A032 1
SCREWS
S1 nsp SCREW , SPECIAL CHD3A012R 21
S2 nsp SCREW CTWS3+10GR 1
S3 nsp SCREW CTB3+6JR 1
S4 nsp SCREW CTB3+10JR 24
S5 nsp SCREW CTBD3+8JFZR 14
S6 nsp SCREW CTWD4+8FFZR
S7 nsp SCREW CTBD3+6FFZR 13
S8 nsp SCREW CTW3+8JR 11
S9 nsp SCREW CTW3+12JR 3
S10 nsp SCREW , SPECIAL CHD1A023R 4
S11 nsp SCREW CTB3+8JR 26
S12 nsp SCREW CTBD3+8JFZR 3
S13 nsp SCREW
CTBD4+8JFZR 6
S14 nsp SCREW CTB3+6FR 6
★
S15 nsp SCREW CTB3+8JFZR 5
WIRES
★
M12 943606501250S CARD CABLE (1mm, 23P, 450mm, B) CWC4F2A23A450B10 1
★
M13 943606501240S CARD CABLE (1mm, 40P, 250mm, B) CWC4F2A40A250B08 1

Denon AVR-2312 Specifications

General

Impedance	8 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@8 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFD
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11000 g
