AVR-3806 / AVC-3920
PARTS LIST OF P.W.B. UNIT
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Note: The symbols in the column "Remarks" indicate the following destinations.
BKEU : U.S.A. model(Black) SREU : U.S.A. model (Silver) BKEC : Canada model(Black) SREC : Canada model (Silver)
1U-3700 MAIN CPU P.W.B. UNIT ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC501,502 00D 262 2375 904 TC4094BF(TP1) +C
IC504 00D 262 2375 904 TC4094BF(TP1) +C
IC506 00D GEN 8013 MAIN CPU SUB ASS'Y M30626****
IC508 00D 262 2375 904 TC4094BF(TP1) +C
IC902,903 00D 262 3564 905 TC74VHCU04F
IC904 00D 262 3561 908 TC74VHC14F
IC905,906 00D 262 2213 901 TC74HC151AF +C
IC907-910 00D 262 3387 001 TORX142(F)
IC911,912 00D 262 3386 002 TOTX142(F)
IC913 00D 262 3561 908 TC74VHC14F
IC915 00D 263 1100 021 KIA7812API
TR107 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR108,109 00D 271 0312 905 2SA/KTA1504SGR-RTK +C
TR110 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR501 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR502 00D 271 0326 904 2SA1954(B)-TE85L
TR503,504 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR505 00D 269 0193 901 KRC104S-RTK(47K-47K) +C
TR507 00D 269 0191 903 KRA104S-RTK(47K-47K) +C
TR508 00D 269 0193 901 KRC104S-RTK(47K-47K) +C
TR509 00D 271 0326 904 2SA1954(B)-TE85L
TR510 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR513 00D 271 0326 904 2SA1954(B)-TE85L
TR517 00D 271 0326 904 2SA1954(B)-TE85L
TR518 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR519 00D 269 0193 901 KRC104S-RTK(47K-47K) +C
TR520 00D 269 0191 903 KRA104S-RTK(47K-47K) +C
TR521 00D 269 0193 901 KRC104S-RTK(47K-47K) +C
TR523 00D 269 0193 901 KRC104S-RTK(47K-47K) +C
TR524 00D 273 0464 901 KTC3875SGR-RTK +C
TR801-824 00D 273 0460 905 KTC2875B-RTK +C
TR825-832 00D 269 0184 907 KRA102S-RTK +C
TR902,903 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR904 00D 269 0086 908 DTA114TKT96 +C
TR905,906 00D 269 0066 902 DTC323TKT96 +C
D501,502 00D 276 0704 903 1SR35-400A(T93X)
D503 00D 276 0794 900 KDS160 +2125
D504 00D 276 0454 910 HZS3C-2TD
D505 00D 276 0794 900 KDS160 +2125
D801-803 00D 276 0704 903 1SR35-400A(T93X)
D804 00D 276 0683 901 UDZS5.6B-TE17 +C
D901,902 00D 276 0738 908 KDS226-RTK(A-K) +C
X501 00D 399 1041 007 X-TAL(12MHZ)
RESISTORS GROUP
R579 00D 241 2387 908 RD14B2E010JNBST
R588 00D 241 2387 908 RD14B2E010JNBST
RR837 00D 244 2055 996 RS14B3A122JNBST(S)
RR839,840 00D 244 2055 996 RS14B3A122JNBST(S)
