4. RADIATOR ASSY
(1) Remove the screws.
(2) Disconnect the connector wires, then remove the screws.
TOP
COVER
HDMI UNIT
→
INPUT UNIT
→
RADIATOR ASSY
→
Proceeding :
Direction of photograph: A
RADIATOR ASSY
CN71 CN44
CN45
CN41
CN47 CN48
CN46
