IC512
1
SN74LV4040APW
INPUT
SELECTOR (9) (3)
(11)
(2)MCLK
(10)
(7)
(26)BCLK
IC104
(13)
(25)LRCLK
SN74HC
(10)
(27)SDATA
151APW
CKOUT(13) FRONTch
(5) (5)DIN2 BCK(14)
LRCK(15)
DATAD(16)
XIN(22)
12.287MHz
IC113
(2)MCLK
SG-8002
(7) (26)BCLK
(13) (25)LRCLK
(3) (10) (27)SDATA
IC112 CENTERch
SN74LV4040APW
(2) (13) (4) (15)
(7) (18) (8) (19)
SUBWOOFERch
RFS0 RFS1 RCLK0 RCLK1
TFS0 TFS1 TCLK0 TCLK1
MCLK(17)
TCLK0(8)
(4)RCLK0
AIN SCLK(18)
TCLK1(19)
(15)RCLK1
LRCK(19) (2)MCLK
SDATA(21) TFS0(7) (2)RFS0 (26)BCLK
TFS1(18)
(13)RFS1
(25)LRCLK
(27)SDATA
(5)DR0A
DT0A(11)
(5)DR0A
DT0A(11)
DT0B(12)
(6)DR0B
DT0B(12)
SURROUNDch
DT1A(22)
(16)DR1A
DT1A(22)
DT1B(23)
(17)DR1B
DT1B(23)
(2)MCLK
(26)BCLK
(25)LRCLK
(27)SDATA
SURROUND BACKch
DIR
IC111
LC89055W
A/D CONVERTER
AD1854K
IC114
AK5353VS
IC107
74LVX157MTC
2nd DSP1st DSP
A/D SELECTOR
IC502
ADSP-21065L
IC501
ADSP-21065L
IC511
D/A CONVERTER
IC305
AD1854K
IC307
IC301
AD1854K
IC303
AD1854K
SYNC
SN74LV86APW
SN74LV00APW
IC523
256fs
64fs
fs
DATA
DATA
256fs
64fs
fs
FRONT
CENTER/SW
SURROUNDSURROUND BACK
fs
64fs
2
3
DOLBY DIGITAL Decode
DTS-ES Decode
AL24 Processing
THX Filter Processing
EX/ES Matrices Processing
Sound Simulation
Bus-Management Processing
* fs is a sampling frequency of input digital signal.
e.g.: sampling frequency 48 kHz → fs=48 kHz
* 64fs and 256fs are 64 or 256 times the sampling frequency
respectively.
e.g.:sampling frequency 48 kHz
64fs:48kHz x 64 = 3.072MHz
256fs:48kHz x 256 = 12.288MHz
* The sampling frequency for analog input is fixed to 48kHz internally.
* (No.) indicates the pin number of individual IC.
* The arrow indicates the direction of signal flow. As the input terminal
pointed by the arrowhead and the output terminal by the opposite.
