32
AVR-5805/AVC-A1XV-UPGRADE
Page 150~158
PARTS LIST OF P.W.B. UNIT ASS’Y
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
00D1U-3755A D.VIDEO P.W.B. UNIT ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101,102 00D 262 3416 901 BR24L02F-WE2
IC103 00D 262 3654 006 SII9033CTU
IC104 00D 262 3642 908 LM1117MPX-1.8/NOPB
IC105,106 00D 262 2977 946 BA33BC0FP-E2 +REF
IC151,152 00D 262 3416 901 BR24L02F-WE2
IC153 00D 262 3654 006 SII9033CTU
IC154 00D 262 3642 908 LM1117MPX-1.8/NOPB
IC155,156 00D 262 2977 946 BA33BC0FP-E2 +REF
IC201,202 00D 262 3416 901 BR24L02F-WE2
IC203 00D 262 3654 006 SII9033CTU
IC204 00D 262 3642 908 LM1117MPX-1.8/NOPB
IC205,206 00D 262 2977 946 BA33BC0FP-E2 +REF
IC251 00D GEN 8244 HDMI SW PLD SUB ASSY EPM570T144C5N *
IC252 00D 262 2977 946 BA33BC0FP-E2 +REF
IC301 00D 262 2977 946 BA33BC0FP-E2 +REF
IC302 00D 262 3642 908 LM1117MPX-1.8/NOPB
IC303 00D 262 3364 011 SII9030CTU-7
IC351 00D 262 2977 946 BA33BC0FP-E2 +REF
IC352 00D 262 3642 908 LM1117MPX-1.8/NOPB
IC353 00D 262 3364 011 SII9030CTU-7
IC401 00D 262 3611 007 EP1C4F400C8N *
IC402 00D 262 3290 907 PQ015EZ5MZ +REF
IC403 00D GEN 8245 VIDEO SW ROM ASSY EPCS1SI8N(TAPE) *
IC404 00D 262 2977 946 BA33BC0FP-E2 +REF
IC451 00D GEN 8246 AUDIO SW PLD SUB ASSY EPM570T144C5N *
IC452 00D 262 2977 946 BA33BC0FP-E2 +REF
IC453 00D 262 2977 917 BA25BC0FP-E2
IC454,455 00D 262 3120 909 SN65LVDS31PW +REF
IC456 00D 262 3432 901 SN65LVDS1DBVR
IC457 00D 262 3291 003 SM5819A +C
IC501 00D 262 3577 002 FLI2310-LF-CF
IC502 00D 262 3642 908 LM1117MPX-1.8/NOPB
IC503,504 00D 262 2977 946 BA33BC0FP-E2 +REF
IC505 00D 262 3598 007 K4S643232H-UC60
IC601 00D 262 3447 909 TC4053BFT
IC602 00D 262 2977 946 BA33BC0FP-E2 +REF
IC603 00D 262 3519 905 PQ018EZ01ZPH
IC604 00D 262 2977 946 BA33BC0FP-E2 +REF
IC605 00D 262 3620 001 TE8201PF *
IC606 00D 262 3495 003 ADV7403BSTZ-110
IC607 00D 262 3519 905 PQ018EZ01ZPH
IC608 00D 263 1198 907 LT1399CS +REF
IC609,610 00D 263 1082 903 TK15420MTL +C
IC611 00D 262 2977 946 BA33BC0FP-E2 +REF
IC612,613 00D 263 1082 903 TK15420MTL +C
IC701 00D 262 2977 946 BA33BC0FP-E2 +REF
IC702 00D 262 2977 917 BA25BC0FP-E2
IC703 00D 262 3478 004 ADV7320
IC704 00D 262 2977 917 BA25BC0FP-E2
IC705 00D 262 3621 903 FMS6403MTC20X_NL *
IC751 00D 262 2977 946 BA33BC0FP-E2 +REF
