Denon AVR-589 Service Manual

110
AVR-1709/1609/1519/1509/689/589, AVC-1509
C1401,1402 00D9609010751 C,ELECT 4.7UF-M/50V AVC1509 D0404R7087090S
C1409 nsp C,CERAMIC 0.01UF-K/50V AVC1509 D011103777160S
C1410-1413 00D9609010751 C,ELECT 4.7UF-M/50V AVC1509 D0404R7087090S
C1418 nsp C,CERAMIC 0.01UF-K/50V AVC1509 D011103777160S
OTHERS PARTS GROUP
CN109,110 nsp CN.WAFER 5P
L101100030510S
CN406 nsp CN,WIRE 3P L000261030071S
CN1001 nsp CN.WAFER 8P L101100030810S
CN1002 nsp CN.WAFER 10P L101100031010S
CN1003 nsp CN.WAFER 6P L101200100620S
CN1004 nsp CN,WIRE 6P L000121060120S
CN1005 nsp CN,WIRE 4P L000161040091S
CN1006 nsp CN.WAFER 10P L101100031010S
CN1301,1302 nsp CN.HOUSING 12P AVC1509 L120912120010S
CN1303,1304 nsp CN.WAFER 9P AVC1509 L101100040910S
CP110 nsp CN.WAFER 5P L101100040510S
CP706 nsp CN.WAFER 11P L101100031110S
CP1301,1302 nsp CN.WAFER 12P AVC1509 L100912120010S
CP1303,1304 nsp CN.WAFER 9P AVC1509 L101100030910S
JACK1302 00D9630218108 TER,RCA 3PIN G60630401000YS
JACK1303 963646001770S TER,RCA 9PIN AVR1509E2 G607902AD013Y
S
JACK1307 00D9630218001 TER,RCA 2PIN G60122001000YS
JACK1310-1312 00D9630262701 CN.CATV 14P AVC1509 L170001200020S
nsp HEAT SINK 2120044338010S
nsp HEAT SINK 2120210958010S
nsp SCREW(3X8 B-TYPE ZNY/BH) B020030081B10S
Ref. No. Part No. Part Name Remarks Q'ty New
