AVR-1709/1609/1519/1509/689/589, AVC-1509
6. CHASSIS BACK SUB ASSY
(1) Remove the screws.（ねじをはずす。）
7. VIDEO P.W.B ASSY
(1) Disconnect the connector wires.（コネクタワイヤーをはずす。）
proceeding (手順): CABINET TOP → HDMI P.W.B ASSY → SIRIUS P.W.B ASSY
→ TUNER PACK → SPEAKER P.W.B ASSY
→ CHASSIS BACK SUB ASSY
Picture B
ً
proceeding (手順): CABINET TOP → HDMI P.W.B ASSY → SIRIUS P.W.B ASSY
→ TUNER PACK → SPEAKER P.W.B ASSY
→ CHASSIS BACK SUB ASSY → VIDEO P.W.B ASSY
VIDEO P.W.B ASSY
Picture D
CN1002
CN1006
CN1003CP514
CN1001
