Denon AVR-589 Service Manual

124
AVR-1709/1609/1519/1509/689/589, AVC-1509
★ 95
00D9630280107 TR NPN 2SC3964
Q103C,Q103FL,Q103FR,Q103
SL,Q103SR
J502396400000S 5
★ 96
00D9960018706 TR NPN 2SD2390-Y
Q101C,Q101FL,Q101FR,Q101
SL,Q101SR
J5032390Y0000S 5
★ 97
nsp LABEL FUSE CAUTION
E3 5507000001110S 1
SCREWS
A nsp SCREW,TAP TITE +2S 3*8 B-TYPE
ZNW/BH
AVR1709 B020030081B10S 73
A nsp SCREW,TAP TITE +2S 3*8 B-TYPE
ZNW/BH
AVR1609, 1509, 1519SPE1C,
589, AVC1509
B020030081B10S 72
A nsp SCREW,TAP TITE +2S 3*8 B-TYPE
ZNW/BH
AVR689 B020030081B10S 70
B nsp SCREW +2S 3*8 BK WASHER PI12
BK model 1500001456020S 5
B nsp SCREW +2S 3*8 NI WASHER PI12
PS model 1500001456030S 5
C nsp SCREW,TAP TITE +2S 3*15 B-TYPE
ZNW/BH
B020030151B10S 2
D nsp SCREW,TAP TITE +2S 3*10 B-
TYPE(DOT) BK/BH
AVR1709BKE3 B020030103B11S 38
D nsp SCREW,TAP TITE +2S 3*10 B-
TYPE(DOT) BK/BH
AVR1709BKE2/SPE2,
1609BKE3, 689BKE3
B020030103B11S 37
D nsp SCREW,TAP TITE +2S 3*10 B-
TYPE(DOT) BK/BH
AVR1709SPE1C B020030103B11S 36
D nsp SCREW,TAP TITE +2S 3*10 B-
TYPE(DOT) BK/BH
AVR1509BKE2/SPE2 B020030103B11S 35
D nsp SCREW,TAP TITE +2S 3*10 B-
TYPE(DOT) BK/BH
AVR689BKEA B020030103B11S 35
D nsp SCREW,TAP TITE +2S 3*10 B-
TYPE(DOT) BK/BH
AVR1509SPE1C, 1519SPE1C,
589BKE3/BKEA
B020030103B11S 34
D nsp SCREW,TAP TITE +2S 3*10 B-
TYPE(DOT) BK/BH
AVC1509SPJP B020030103B11S 31
E nsp SCREW,TAPPING ASSY +2S 3*14
P(ÉŠ6)+S-WASHER ZNY/HH
AVR1709, 1609, 689 B018230141H11S 22
E nsp SCREW,TAPPING ASSY +2S 3*14
P(ÉŠ6)+S-WASHER ZNY/HH
AVR1509, 1519, 589, AVC1509 B018230141H11S 16
F nsp SCREW,TAP TITE +2S 3*17 B-TYPE
ZNW/BH
B020030171B10S 3
G 00D9630048307
SCREW +2S 4*8 B-TYPE(DOT) BK/BH BK model 1500040083B10S 6
G 00D9639004012 SCREW +2S 4*8 B-TYPE(DOT) NI/BH
SP model 1500040084B10S 6
H nsp SCREW,TAP TITE ASSY +3S 4*10
P+S-WASHER ZNW/BH
B028940101B10S 4
I nsp SCREW +2S 3*8 ZnY WASHER PI12
1500001456010S 3
J nsp SCREW,TAP TITE +3S 4*6 S-TYPE
ZNW/BH
B020740061B10S 6
K nsp SCREW,TAP TITE +2S 3*5 B-TYPE
ZNW/BH
E2, E1C, EA, JP B020030051B10S 2
L nsp SCREW +2S 3*10 BK/FH
E2, E1C, EA, JP B020030103F10S 2
P nsp SCREW +2S 3*8 PI9.5 B-TYPE ZNW
1500001206010S 4
Q nsp SCREW,TAP TITE +3S 3*8 BK/BH
AVR1709, 689 B020930083B10S 5
Q nsp SCREW,TAP TITE +3S 3*8 BK/BH
AVR1609, 1509, 1519C, 589,
AVC1509
B020930083B10S 4
R nsp SCREW,TAP TITE +2S 3*6 B-TYPE
BK/BH
B020030063B10S 2
S nsp SCREW,TAP TITE +2S 2x8 B-TYPE
BLACK/BH
AVC1509SPJP B020020081B10S 6
T nsp SCREW,MACHINE +M 3*10 BK/BH
E3 B000030103B10S 1*
Ref. No. Part No. Part Name Remarks Q'ty New
