Denon AVR-684 Service Manual

35
35
AVR-1604/684 / AVC-1580
CPU P.W.B. UNIT
Ref. No. Part No. Part Name Remarks New
SEMICONDUCTORS GROUP
IC201 963 0121 305 IC CXP740096-178Q
IC202 963 0057 602 IC TDA7330BD E2,EK,E2A
IC271 963 0114 707 IC MC7812CT
IC301 960 0180 004 IC LC75721E
IC302 963 0074 504 IC BU2090F
IC391 963 0113 106 IC GP1FA513RZ E3,EU,E2,EK,E2A,E1C,EUT,E1K
RMC301 960 0181 100 IC NJL64H380A
Q201 963 0121 402 Transistor KRC104S
Q202 963 0121 509 Transistor KTC3875S
Q251 960 0097 207 Transistor KRA102M
Q252,253 960 0196 603 Transistor KTC2874B
Q261 963 0102 803 Transistor 2SA933S E2,EK,E2A
Q262 963 0121 606 Transistor KRC107S E2,EK,E2A
Q310 963 0120 704 Transistor KRA102S
Q311 963 0120 801 Transistor KRC102S
Q312 963 0120 704 Transistor KRA102S
Q313 963 0120 801 Transistor KRC102S
Q314 963 0120 704 Transistor KRA102S
Q315 963 0120 801 Transistor KRC102S
Q316 963 0121 402 Transistor KRA104S
D201 963 0096 605 Diode 1N4148WS
D202 963 0058 407 Diode IN4007
D203 963 0020 309 Diode 1SS133T
D204,205 963 0096 605 Diode 1N4148WS
D206 963 0020 309 Diode 1SS133T E2,EK,E2A
D251 963 0058 407 Diode IN4007 E3,EU,E2,EK,E2A,E1C,EUT,E1K
D302-304 963 0020 309 Diode 1SS133T
D305 963 0096 605 Diode 1N4148WS
D308,309 963 0096 605 Diode 1N4148WS
ZD201 963 0047 502 Zener diode MTZJ3.3B
ZD301 960 0095 801 Zener diode MTZJ6.8B
ZD331,332 960 0095 500 Zener diode MTZJ5.1B
ZD335,336 960 0095 500 Zener diode MTZJ5.1B
LED301-304 960 0197 204 LED PI5-RD/HL50RDRF4T
LED305 960 0197 204 LED PI5-RD/HL50RDRF4T N
LED306-309 960 0197 204 LED PI5-RD/HL50RDRF4T
LED310 963 0114 804 LED HL-50GDGF4T
RESISTORS GROUP
R271 963 9006 272 Metal oxide 4.7 ohm 1W
CAPACITORS GROUP
BC201 963 9006 243 Electrolytic 3300uF/6.3V E3,EU,N
BC201 963 0061 504 Electrolytic 8200uF/5.5V E2,EK,E2A,E1C,EUT,E1K
C201 963 9004 698 Ceramic chip 0.01uF/50V
