Speaker configuration and “Amp Assign” settings
This unit has a built-in 7-channel power amplifier. In addition to the basic 5.1-channel system, a variety of speaker systems can be configured by changing
the “Amp Assign” settings to suit the application, such as 7.1-channel systems, bi-amp connections and 2-channel systems for multi-zone playback.
(v p. 187)
Perform “Amp Assign” settings to suit the number of rooms and speaker configuration to be installed. (v p. 187)
Playback speaker and zone
“Amp Assign” settings
Connection
page
MAIN ZONE ZONE2
5.1-channel 2-channel (Pre-out) Can be set in all “Amp Assign” modes. 41
7.1-channel (surround back) 2-channel (Pre-out) Surround Back 42
7.1-channel (front height) 2-channel (Pre-out) Front Height 43
7.1-channel (top front) 2-channel (Pre-out) Top Front 44
7.1-channel (top middle) 2-channel (Pre-out) Top Middle 45
7.1-channel (front Dolby Atmos Enabled speaker) 2-channel (Pre-out) Front Dolby 46
7.1-channel (surround Dolby Atmos Enabled speaker) 2-channel (Pre-out) Surround Dolby 47
5.1-channel (bi-amp connection for front speaker) 2-channel (Pre-out) Bi-Amp 48
5.1-channel + second pair of front speaker 2-channel (Pre-out) Front B 49
5.1-channel
2-channel
(Speaker out)
ZONE2 (Default) 50
0
The sound mode that can be selected varies according to the speaker configuration. See “Sound modes and channel output” (v p. 253) for the sound modes that are
supported.
