DVD-2900
Pin Assignment
NC: NO Connection
TO: Tri-State Output
AO: Analog Output
AI: Analog Input
No Name I/O No Name I/O No Name I/O No Name I/O
1 GND - 53 MA[3] O 105 CLKO O 157 PDR[8] O
2 BCLK I 54 MA[4] O 106 CLKIN I 158 PDR[9] O
3 BDEN I 55 MA[2] O 107 AVDD18 - 159 LRCLK O
4 BDREQ O 56 VDD18 - 108 AGND18 - 160 CDLRCK I
5 BSECH I 57 VDD33 - 109 NCO NC 161 CDBCK I
6 HD[0] I/O 58 MA[5] O 110 NCO NC 162 CDDATA I
7 HD[1] I/O 59 MA[1] O 111 NCO NC 163 CDDIN I
8 HD[2] I/O 60 MA[6] O 112 GND - 164 AO0 O
9 HD[3] I/O 61 MA[0] O 113 AVDD33 - 165 GND -
10 HD[4] I/O 62 MA[7] O 114 DAOUTB AO 166 AO1 O
11 HD[5] I/O 63 MA[10] O 115 AVRI AI 167 AO2 O
12 VDD18 - 64 GND - 116 PAB AO 168 AOD O
13 VDD33 - 65 MA[8] O 117 IREF AI 169 AAD O
14 HD[6] I/O 66 MBA[1] O 118 BIAS2 AI 170 DOUT0 O
15 HD[7] I/O 67 MA[9] O 119 PAY AO 171 DOUT1 O
16 HD[8] I/O 68 MBA[0] O 120 BIAS1 AI 172 ACLKI I
17 HD[9] I/O 69 MA[11] O 121 AVDD33 - 173 DACCLK O
18 HD[10] I/O 70 DCS O 122 PAR AO 174 VDD18 -
19 HD[11] I/O 71 VDD18 - 123 AVDD33 - 175 VDD33 -
20 GND - 72 VDD33 - 124 AGND33 - 176 DOCLK O
21 HD[12] I/O 73 DCS2 O 125 GND - 177 PWD TO
22 HD[13] I/O 74 DCS3 O 126 NC0 NC 178 CSYNC I
23 HD[14] I/O 75 DCS4 O 127 NCO NC 179 OSDKEY O
24 HD[15] I/O 76 DCS5 O 128 NCO NC 180 VSYNC O
25 HA[0] I 77 RAS O 129 NCO NC 181 HSYNC O
26 HA[1] I 78 CAS O 130 NCO NC 182 PXCLKP O
27 VDD18 - 79 MCLK O 131 NCO NC 183 PXCLK O
28 VDD33 - 80 DWE O 132 NCO NC 184 PD[0] O
29 HA[2] I 81 GND - 133 NCO NC 185 PD[1] O
30 HA[3] I 82 DQMU O 134 VDD18 - 186 PD[2] O
31 HA[4] I 83 DQML O 135 VDD33 - 187 GND -
32 HA[5] I 84 MD[7] I/O 136 NCO NC 188 PD[3] O
33 HA[6] I 85 MD[8] I/O 137 NCO NC 189 PD[4] O
34 HA[7] I 86 MD[6] I/O 138 NCO NC 190 PD[5] O
35 GND - 87 MD[9] I/O 139 NCO NC 191 PD[6] O
36 HA[8] I 88 VDD18 - 140 NCO NC 192 PD[7] O
37 HA[9] I 89 VDD33 - 141 NCO NC 193 RESET I
38 HA[10] I 90 MD[5] I/O 142 NCO NC 194 HMODE[0] I
39 HA[11] I 91 MD[10] I/O 143 NCO NC 195 HMODE[1] I
40 CS I 92 MD[4] I/O 144 NCO NC 196 TEST[0] I
41 RE I 93 MD[11] I/O 145 GND - 197 TEST[1] I
42 VDD18 - 94 MD[3] I/O 146 NCO NC 198 VDD18 -
43 VDD33 - 95 MD[12] I/O 147 NCO NC 199 VDD33 -
44 WE I 96 GND - 148 NCO NC 200 TEST[2] I
45 BHE I 97 MD[2] I/O 149 NCO NC 201 BD[0] I
46 RDY TO 98 MD[13] I/O 150 NCO NC 202 BD[1] I
47 INT1 O 99 MD[1] I/O 151 NCO NC 203 BD[2] I
48 INT2 O 100 MD[14] I/O 152 NCO NC 204 BD[3] I
49 INT3 O 101 MD[0] I/O 153 NCO NC 205 BD[4] I
50 GND - 102 MD[15] I/O 154 NCO NC 206 BD[5] I
51 DREQ O 103 VDD18 - 155 VDD18 - 207 BD[6] I
52 DACK I 104 VDD33 - 156 VDD33 - 208 BD[7] I
