Denon DVD-2930 Service Manual

140
DVD-2930/2930CIE1C
C606-610 nsp 00D 257 0512 903 CK73F1E104ZT +1608
C611 00D 254 4693 939 CE04W1H101MT(RF0)
C612,613 00D 255 4254 915 CQ93P2A102JT(NH2)
C614-620 00D 254 4693 939 CE04W1H101MT(RF0)
C621-628 nsp 00D 257 0508 917 CC73CH1H471JT +1608
C997,998 00D 255 4253 932 CQ93P2A471JT(NH2)
OTHERS PARTS GROUP
CX041 nsp 00D 205 0343 045 4P CONN.BASE(KR-PH)
CX062 nsp 00D 205 0343 061 6P CONN.BASE(KR-PH)
CX124 nsp 00D 205 1386 085 12P BASE(9115B-PT1)
CX125 nsp 00D 205 0536 027 12P CONNE SOCKET
CX131 00D 205 1383 020 13P-FFC-BASE(9615C)
CX163 nsp 00D 205 1387 026 16P BASE(9115B-PT1)
CX164 nsp 00D 205 0773 000 16P SOCKET(9110S)
CY034 nsp 00D 205 0653 036 3P VH CON.BASE
CY044 nsp 00D 205 0343 045 4P CONN.BASE(KR-PH)
CY124 nsp 00D 205 0536 027 12P CONNE SOCKET
CY125 nsp 00D 205 1386 085 12P BASE(9115B-PT1)
CY163 nsp 00D 205 0773 000 16P SOCKET(9110S)
CY164 nsp 00D 205 1387 026 16P BASE(9115B-PT1)
CY331 00D 205 1383 004 33P-FFC-BASE(9615C)
FB301 00D 235 0130 903 CHIP EMIFIL(11A121) +1608
JK205 00D 205 1222 000 RJ-45 JACK(GND)
JK301 00D 204 8731 009 6P PIN JACK(21-3995)
JK302,303 00D 204 8728 009 1P PIN JACK(BK)-LF
JK306 00D 204 8728 009 1P PIN JACK(BK)-LF
L501 00D 235 0125 905 INDUCTOR(FLC32C220K)+3216
W101 - M3-SCREW-TERMINAL08R
X101 00D 399 1017 002 X-TAL(24.576MHZ)
X301 00D 399 0951 004 X'TAL(25MHZ)
Ref. No. nsp Part No. Part Name Remarks Q'ty New
