46
DVD-1930CI / DVD-757
LEAD IDENTIFICATIONS
12 3
8
5
4
1
1: R
2: A
3: K
123
1
2
4
3
1: A
2: K
3: E
4: C
1: GND
2: Vout
3: Vin
E
CB
E
CB
123
16
9
8
1
16
9
8
1
28
15
14
1
G D S
EC B
BCE
Note:
A: Anode
K: Cathode
E: Emitter
C: Collector
B: Base
R: Reference
G: Gate
D: Drain
S: Source
KIA4558P/P
UTC4558
MM1636XWRE
CXA1511M-T4
NJM4580M-TE1
2SA1015-Y(TE2 F T)
2SA966-Y(TE6 F M)
KTA1266-Y-AT/P
KTA1273-Y-AT/P
KTC3205-Y-AT/P
2SC1815-GR(TE2 F T)
KTA1267-Y-AT/P
KTC3199-GR-AT/P
KRA105M-AT/P
KRA110M-AT/P
EL817B
EL817C
LTV-817C-F
PS2561A-1(W)
KIA2431AP-AT/P
TL432A-TA
MM1637XVBE
PT6313-S-TP(L)
SC16313G
GP1FA513TZ0F
ADM232AARN
LM1117S-ADJ
LD1117SC-R
TLV1117IDCYRG3
UTC1117YA
2SK3563
2SD2144S
KTD882
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon DVD-757 Specifications

Audio Specifications

frequency response (DVD)	4 Hz - 22 kHz (48kHz sampling), 4 Hz - 44 kHz (96kHz sampling), 4 Hz - 88 kHz (192kHz sampling)
frequency response (CD)	4 Hz - 20 kHz
frequency response (Super Audio CD)	4 Hz - 100 kHz
signal-to-noise ratio	115 dB
dynamic range (DVD)	100 dB
dynamic range (CD)	98 dB
total harmonic distortion	0.004% at 1 kHz CD

Video Specifications

signal system	NTSC
composite video output	1.0 Vp-p (with 75 ohms load)
S-Video output (Y)	1.0 Vp-p (with 75 ohms load)
S-Video output (C)	0.286 Vp-p
component video output (Y)	1.0 Vp-p (with 75 ohms load)
component video output (Pb/Cb)	0.648 Vp-p (with 75 ohms load)
component video output (Pr/Cr)	0.648 Vp-p (with 75 ohms load)

Power

power supply	AC 120 V, 60 Hz
power consumption	15 W
standby power consumption	1 W

Weight and Dimensions

dimensions	435 (W) x 75 (H) x 310 (D) mm, 17-3/32” (W) x 2-61/64” (H) x 12-13/64” (D)
weight	2.6 kg, 5.72 lbs
