DVD-1930CI / DVD-757

DVD-1930CI / DVD-757 PARTS LIST OF EXPLODED VIEW

＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。

＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.

＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。

＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.

Note: The symbols in the column "Remarks" indicate the following destinations.

A : DVD-1930CIBKE3 model

B : DVD-757BKE3 model

Ref. No. nsp Part No. Part Name Remark Q'ty New

00D9H2 6000 765 DVD MAIN CBA UNIT N79D3KUP 1 *

00D9H2 6000 766 AV ASSEMBLY 1VSA15037 1 *

AV CBA -

FUNCTION CBA -

LED CBA -

INTERFACE CBA -

00D9H2 6000 767 5.1CH CBA 1VSA13235 1 *

A1X 00D9H2 6000 751 FRONT ASSEMBLY 1VM222704 A 1

A1X 00D9H2 6000 752 FRONT ASSEMBLY 1VM222708 B 1

A2 00D9H2 6000 645 TRAY PANEL ASSEMBLY 1VM422186 1 *

A11 00D9H2 6000 566 INSULATOR ASSEMBLY (R) 1VM420732 1 *

A12 00D9H2 6000 567 INSULATOR ASSEMBLY (L) 1VM420733 1 *

A13 00D9H2 6000 323 FOOT 0VM406940A 2 *

A15 00D9H2 6000 611 CHASSIS 1VM120073 1 *

A16 00D9H2 6000 680 TOP COVER(BLACK) 1VM120074C 1 *

A17 00D9H2 6000 753 REAR PANEL 1VM222500 A 1

A17 00D9H2 6000 754 REAR PANEL 1VM222503 B 1

A21 - LABEL SERIAL NO. - 1

1B1 00D9H2 6000 755 DVD MECHA E7 (D) N79D0KVM 1

2B2 - POWER PCB HOLDER 0VM306801E 1

2B3 00D9H2 6000 756 MAIN PCB HOLDER 1VM320650 1

2B4 00D9H2 6000 780 LOADER BASE 0VM101367G 1 *

2B5 - FIP SUPPORT ASSEMBLY 1VM424564 1

2B6 00D9H2 6000 757 JACK PCB HOLDER 0VM101376E 1

2B9 00D9H2 6000 758 D SUB HOLDER 1VM323220 1

2B34 00D9H2 6000 769 CUSHION SPACER 1VM422273 2

2B39 00D9H2 6000 770 REINFORCE PLATE 1VM321919 1

SCREWS

2L011 -

SCREW TAP TIGHT M3X5 BIND HEAD+BLK NI

GBHC3050 5

2L021 - SCREW P-TIGHT M3*12 BIND+ GBJP3120 4

2L023 - SCREW C-TIGHT M3X6 BIND HEAD+ GBJC3060 2

2L041 - SCREW B-TIGHT M3X8 BIND HEAD+ GBHB3080 8

2L043 -

SCREW TAP TIGHT M3X5 BIND HEAD+BLK NI

GBHC3050 1

2L051 - SCREW C-TIGHT M3X8 BIND HEAD+ GBJC3080 2

2L052 - SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080 6

2L071 -

SCREW TAP TIGHT M3X5 BIND HEAD+BLK NI

GBHC3050 1

2L081 00D9H2 6000 759 HEXAGON SPACER 1VM424730 2

2L101 - SCREW C-TIGHT M3X6 BIND HEAD+ GBJC3060 1

2L102 - SCREW C-TIGHT M3X6 BIND HEAD+ GBJC3060 4

2L105 - SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080 3

2L106 - SCREW C-TIGHT M3X6 BIND HEAD+ GBJC3060 4

2L107 - SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080 1

2L108 - SCREW C-TIGHT M3X6 BIND HEAD+ GBJC3060 2

2L109 - SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080 1

2L112 - SCREW C-TIGHT M3X6 BIND HEAD+ GBJC3060 1

2L113 - SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080 1

2L114 - SCREW TAP TIGHT WASHER+P-TIGHT GCJP3080 2
