DVD-5900/DVD-A11
PARTS LIST OF P.W.B. UNIT ASS'Y
GU-3512 MAIN UNIT ASS’Y
Ref.No. Part No. Part Name Remarks New
SEMICONDUCTORS GROUP
IC101 262 3046 902 TC7WH157FU
IC104 GEN6334-1 IC104 FE/BE ROM SUB ASS'Y MX29LV160BTC-90
IC105 262 3304 903 TC7WH14FU(TE12L) *
IC106 262 3052 909 SM8701BM
IC107 262 2801 902 SN74AHCT273PW-EL2
IC108 262 3252 000 ES6138F(SC) *
IC110 262 3046 902 TC7WH157FU
IC111 262 2391 904 TC7W32F(TE12L)
IC112,113 262 3242 900 SN74LV273APW-EL2 *
IC114 262 3119 004 W986416DH-7
IC115 262 3242 900 SN74LV273APW-EL2 *
IC116 262 3251 904 S-24CS08AFJ-TB *
IC117 262 3269 909 SN74LVC125APW-EL2
IC119,120 262 2669 908 SN74LV157APW
IC122 262 2517 908 SN74LV08APW-EL2
IC123-125 262 2669 908 SN74LV157APW
IC401 262 3282 009 EPM3128ATC100-10
IC402 262 2875 006 16M SDRAM(TSOP)-7/8
IC403 262 3195 905 AD8062-SO8
IC404 262 2515 900 SN74LV04APW-EL2
IC405 262 3217 003 CXD2753R
IC501 263 1109 909 AN8471SA
IC502 262 3219 001 CXD1881AR
IC503 262 3221 002 FAN8042
IC504 263 0615 902 BA15218F-DXE2
IC505 262 3210 000 M11L16161SA-45T
IC507 262 3218 002 CXD1885Q
IC508 262 1782 909 TC7S08FTE85L
IC701 262 3303 001 K4S643232#-TC60 *
IC702 262 3240 009 PM0033A *
IC801 262 3291 003 SM5819A
IC901 263 1110 901 PQ070XZ01ZP
IC950 262 2977 917 BA25BC0FP-E2 *
IC951 262 2977 904 BA18BC0FP-E2
TR101 269 0082 902 DTC114EKT96
TR501,502 272 0160 901 2SB1132T100Q
TR503 274 0154 007 2SD1902(R,S)
TR504 272 0110 003 2SB1266(R,S)
D501,502 276 0717 903 1SS355 TE-17
D901,902 276 0717 903 1SS355 TE-17
D950,951 276 0717 903 1SS355 TE-17
RESISTORS GROUP
R580 244 2051 945 RS14B3A010JNBST(S)
R583,584 244 2052 960 RS14B3A221JNBST(S)
R585 244 2050 904 RS14B3A220JNBST(S)
RA101-104 247 9002 912 MNR14=682JEOAB
RA108,109 247 9002 909 MNR14=330JE0AB
RA401-405 247 9003 908 MNR14=220JE0AB
RA501-507 247 9007 904 MNR14=101JE0
RA508-512 247 9007 917 MNR14=103JE0
RA701,702 247 9002 909 MNR14=330JE0AB
RA705-707 247 9007 917 MNR14=103JE0
