Denon S-101 Brochure & Specs

Analog Input
RECOUT
Digital IN
OPTICAL / COAXIAL
Digital OUT
OPTICAL
Video IN
COMPOSITE / S-Video
Monitor OUT
COMPOSITE / S-Video / COMPONENT / HDMI
(*2)
Video Conversion
USB / iPod
Headphone
RS-232C / Trigger out / Remote In/Out
4 (incl. stereo mini x1(front panel))
1
1 / 2
1
2 / 2
1 / 1 / 1 / no
Component conversion
(Composite <-> S-Video,
Composite/S-Video -> Component)
no / yes (front panel)
yes
no / no / no
4 (incl. stereo mini x1(front panel))
1
1 / 2
1
2 / 2
1 / 1 / 1 / 1
Component conversion
(Composite <-> S-Video,
Composite/S-Video -> Component)
yes (front panel) / yes (front panel)
yes
yes / yes / yes
Amplifier
Virtual Surround
Decode
Tone Control
DVD Player
Progressive Scan
Video DAC
HDMI Scaler
iPod Control
iPod type
Control
On-Screen-Display browse / Charge
USB control
Player type
Control
On-Screen-Display browse / Charge
On Screen Display
System setup / Help menu
Other Features
Dolby Virtual Speakers (Reference/Wide)
Dolby Digital, DTS, Dolby Headphone,
Dolby Pro LogicII, WMA, MP3, HDCD
yes
yes
54 MHz/10 bit
no
3rd generation to latest generation
(music / photo)
Remote, Front panel
(Play, Stop, Skip, Cursor etc basic control)
yes / yes
-
-
-
-
yes / yes
AL 24 Processing at STEREO/DIRECT mode,
TIMER (EVERY DAY, ONCE, SLEEP),
Picture Adjust (5 item)
Dolby Virtual Speakers (Reference/Wide)
Dolby Digital, DTS, Dolby Headphone,
Dolby Pro LogicII, WMA, MP3, HDCD
yes
yes (DCDi)
216 MHz/12 bit x2
420P / 720P / 1080i
3rd generation to latest generation
(music / photo)
Remote, Front panel
(Play, Stop, Skip, Cursor etc basic control)
yes / yes
USB portable player / USB memory (Music)
Remote, Front panel
Play, Stop, Skip, Cursor etc basic control
yes / yes
yes / yes
AL 24 Processing at STEREO/DIRECT mode,
DDVC (Dual Discrete Video Circuit),
Super Sub Alias Filter, NSV (Noise Shaped Video),
Denon original drive mechanism,
Picture Adjust (11 item),
TIMER (EVERY DAY, ONCE, SLEEP)
Features
Input/Output Terminals
Audio section
Power output
Input Sensitivity/Input Impedance
Signal-to-Noise Ratio
Tuner section
Band
Reception Frequency Range
Receiving Sensitivity
PRESET
Video section
Video Output Level/Impedance
Standard Video Terminal
S-Video Connector
Component Video Connector
DVD section
Signal system
Disc Type
(*1)
Analog Audio Output
Speaker system
Type
Woofer
Tweeter
Magnetic Shields
Subwoofer
Type
Woofer
Power
Magnetic Shields
General
Power Supply
Power Consumption
Dimensions (W x H x D)
Weight
Accessories
50 W x 2 (4 ohm)
200 mV/47 kΩ/ohms
92 dB (STEREO MODE, DIRECT MODE: ON)
FM/AM
FM: 87.5 MHz to 107.9 MHz
AM: 520 kHz to 1710 kHz
FM: 1.5 µV/ 75 Ω/ ohms
AM: 20 µV
Total:FM/AM:60
1 Vp-p/ 75Ω/ohms
Y (Brightness) signal: 1 Vp-p/ 75Ω/ohms
C (Color) signal: 0.286 Vp-p/ 75Ω/ohms
Y (Brightness) signal: 1 Vp-p/ 75Ω/ohms
C
B/PB (Blue) signal: 0.648 Vp-p/ 75Ω/ohms
CR/PR (Red) signal: 0.648 Vp-p/ 75Ω/ohms
NTSC / PAL Selectable
DVD-VIDEO, VCD, CD-DA, CD-R / RW(JPEG/Kodak Picture CD/WMA/MP3),
DVD-R/RW, DVD+R/RW (Video mode)
Output Level: 2 Vrms (AUX3 OUT)
2 Way 2 Speakers
10 cm Cone Bass-mid x1
2.5 cm High range x1
yes
Active
20 cm Cone x1
100 W
yes
120 V AC, 60 Hz
75 W (67 W + 8 W (iPod)) (At Standby: Approximately 0.7 W)
Main unit: 380 x 97 x 250 mm (Foot height 1 cm)
14-61/64" x 3-13/16" x 9-27/32" (
including feet, knobs, and connectors )
Speaker system: 134 x 335 x 76 mm / 5-9/32" x 13-3/16" x 2-63/64"
Subwoofer: 236 x 368 x 460 mm / 9-9/32" x 14-31/64" x 18-7/64"
Main unit: 4.2 kg / 9 lbs 4 oz
Speaker system: 1.42 kg / 3 lbs 2 oz
Subwoofer: 15.4 kg / 33 lbs 15 oz
Denon original system cable x1, Denon original speaker cable x2,
Video cable x1, FM indoor antenna x1, AM loop antenna x1, AC cable x1, iPod cable x1,
Quick setup sheet x1, Remote Controller with battery x1, Table Top Speaker stand x2,
Wall bracket x2
70 W x 2 (4 ohm)
200 mV/47 kΩ/ohms
93 dB (STEREO MODE, DIRECT MODE: ON)
FM/AM
FM: 87.5 MHz to 107.9 MHz
AM: 520 kHz to 1710 kHz
FM: 1.5 µV/ 75 Ω/ ohms
AM: 20 µV
Total:FM/AM:60
1 Vp-p/ 75Ω/ohms
Y (Brightness) signal: 1 Vp-p/ 75Ω/ohms
C (Color) signal: 0.286 Vp-p/ 75Ω/ohms
Y (Brightness) signal: 1 Vp-p/ 75Ω/ohms
C
B/PB (Blue) signal: 0.648 Vp-p/ 75Ω/ohms
CR/PR (Red) signal: 0.648 Vp-p/ 75Ω/ohms
NTSC / PAL Selectable
DVD-AUDIO, DVD-VIDEO, Super Audio CD, CD-DA, VCD,
CD-R / RW(JPEG/Kodak Picture CD/WMA/MP3), DVD-R/RW,
DVD+R/RW (Video mode)
Output Level: 2 Vrms (AUX3 OUT)
2 Way 3 Speakers
8 cm Cone Bass-mid x2
2.5 cm High range x1
yes
Active
20 cm Cone x1
140 W
yes
120 V AC, 60 Hz
85 W (74.5 W + 8 W (iPod) + 2.5 W (USB)) (At Standby: Approximately 0.7 W)
Main unit: 380 x 97 x 250 mm (Foot height 1 cm)
14-61/64" x 3-13/16" x 9-27/32" (
including feet, knobs, and connectors )
Speaker system: 134 x 335 x 76 mm / 5-9/32" x 13-3/16" x 2-63/64"
Subwoofer: 236 x 368 x 460 mm / 9-9/32" x 14-31/64" x 18-7/64"
Main unit: 4.2 kg / 9 lbs 4 oz
Speaker system: 2.0 kg / 4 lbs 7 oz
Subwoofer: 15.4 kg / 33 lbs 15 oz
Denon original system cable x1, Denon original speaker cable x2,
Video cable x1, FM indoor antenna x1, AM loop antenna x1, AC cable x1,
iPod cable x1, Quick setup sheet x1, Remote Controller with battery x1,
Table Top Speaker stand x2, Wall bracket x2
Specifications
(*1) Discs that have been poorly finalised following recording may be only partially playable or not playable at all.
(*2) Version 1.1 compliant. HDMI audio output capacity is dependent on the monitor being used. HDMI outputs is HDCP compliant.
Video cannot be viewed if connected to a monitor that does not support HDCP; video can be viewed only on HDCP-compliant monitors.
DVD Home Theater System DVD Home Theater System
Floor Speaker Stand for S-101/S-301
ASF-S01(Optional)
Dimensions (W x H x D):
300 x 1,114 x 300 mm
11-51/64” x 43-55/64” x 11-51/64”
(Speaker system included)
Weight:
7.0 kg/unit, 15 lbs 7 oz/unit
E3_301_101.qxd 05.9.13 10:16 Page 14

Denon S-101 Specifications

General

Brand	Denon
Model	S-101
Category	Home Theater System
Language	English
