SYS-65HT/SYS-55HT/SC-C65/SC-A65/DSW-65DSW-65 Section
PARTS LIST OF EXPLODED VIEW
※ 本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
Note: The symbols in the column "Remarks" indicate the following destinations.
E3: U.S.A. & Canada model E2: Europe model
Ref. No. Part No. Part Name Remark Q'ty New
1 00D UDS W650 001 Cabinet Ass'y for silver model BHKXDN131000 1
1 00D UDS W650 002 Cabinet Ass'y for black model BHKXDN085000 1
2 00D UDS W650 003 Woofer LB1000420001 1 *
3 00D UDS W650 004 Oak Feet JD5081000014 4 *
4 00D UDS W650 005 Spikes JZ0010000003 4 *
5 00D UDS W650 006 Screw LS1215010004 8 *
6 00D UDS W650 007 Screw LS1215B07002 10 *
11 00D UDS W651 10 PREAMP P.W.B. UNIT 051-A00432A 1
12 00D DSW 33XG 168 AMP P.W.B. UNIT 051-A00432B 1
13 00D UDS W651 12 POWER P.W.B. UNIT for E3 051-A00434C 1
13 00D UDS W651 11 POWER P.W.B. UNIT for E2 051-A00432C 1
14 - EVA 333-EVA-00783 2
15 - WIRE CLAMP 335-NYL-00002 2
16 - EVA 333-EVA-00807 2
17 - CASE 306-ABS-00206-1BB 1
18 - BRACKET Large-R 361-FE-05008-0LB 1
19 - HEAT SINK 323-AL-00020 1
20 00D UDS W651 02 SUB TRANS for E3 150-e0351201 1
20 00D UDS W651 01 SUB TRANS for E2 150-e0351200 1
21 - BRACKET Small-L 361-FE-05010-0LA 1
22 - BRACKET Small-R 361-FE-05011-0LA 1
23 00D UDS W651 09 BACK PANEL 302-AL-05021-0BB 1
23 00D UDS W651 08 BACK PANEL 302-AL-05021-0BA 1
24 00D DSW 33XG 136 POWER SWITCH 180-prf1003s 1
25 00D UDS W651 05 AC COARD for E3 152-u75201601 1
25 00D UDS W651 06 AC COARD for E2 152-v75202601 1
26 - COVER 309-ABS-05003-0BA 1
27 - HEAT SINK 323-AL-00019-0BB 1
28 00D DSW 33XG 166 BUSH 311-ABS-00028 2
29 - RUBBER SHEET 25*21*2T 336-RUB-00263 4
30 00D UDS W651 04 MAIN TRANS for E3 150-e0865005 1
30 00D UDS W651 03 MAIN TRANS for E2 150-e0865004 1
31 - M4 NUT 354-GM04002 4
32 - PWB HOLDER 361-FE-05013-0LA 1
33 - EVA 333-EVA-00835 2
34 - BRACKET Large-L 361-FE-05008-0LA 1
35 - EVA 333-EVA-00826 2
★ 36
00D DSW 33XG 129 FUSE 125V for E3 154-25006t0 1
★ 36
00D UDS W651 07 FUSE 250V for E2 154-v25006t0 1
★ 37
00D DSW 33XG 123 CERAMIC C 4700P for POWER SWITCH 130-3f472md00 1
★ 38
00D DSW 33XG 130 FUSE HOLDER R3-11 155-520020 1
★ 39
- TUBE 20mm*40mm for AC SW 156-h200040 1
★ 40
- TUBE 20mm*60mm for FUSE HOLDER 156-h200060 1
★ 41
- TUBE 7mm*120mm for AC WIRE 156-h070120
★ 42
- TR BLACKET 361-FE-00051 1
★ 43
- LED HOLDER7.5*7.1*8.25 for LED201 361-NYL-05012-0BA 1
★ 44
- PWB HOLDER 361-FE-00004 1
★ 45
- EVA 333-EVA-00220 6
★ 46
- EVA 333-EVA-05052-0BA 2
