Denon SYS-C3L - Parts List of Exploded View

17
17SYS-T3L/SYS-C3L/SYS-A3L/SYS-A2.1L/SC-T3L/SC-A3L/DSW-3LDSW-3L Section
PARTS LIST OF EXPLODED VIEW
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
Note: The symbols in the column "Remarks" indicate the following destinations.
E3: U.S.A. & Canada model E2: Europe model
JP: Japan model
Ref. No. Part No. Part Name Remarks Q'ty New
1 9H3 0001 452 MAIN P.W.B. UNIT ASS'Y (B063L8B0) for E3 388200 1 *
1 9H3 0001 458 MAIN P.W.B. UNIT ASS'Y (B063L8C0) for E2 388182 1 *
1 9H3 0001 456 MAIN P.W.B. UNIT ASS'Y (B063L8A0) for JP 386228 1 *
1-1 - AMPLIFIER UNIT-1
1-2 - AMPLIFIER UNIT-2
1-3 - PREAMPLIFIER UNIT
1-4 - MAIN TRANS UNIT
1-5 - SUB TRANS UNIT
2 9H3 0001 448 ENCLOSURE (E2/E3) for E3,E2 389887 1 *
2 9H3 0001 443 ENCLOSURE (JP) for JP 391468 1 *
3 9H3 0001 011 CONE SPEAKER C160 380418 1
4 9H3 0001 441 GRILLE ASSY 388433 1 *
5 9H3 0001 444 SUPPORT 387796 4 *
6 9H3 0001 449 BASE BOARD (E2/E3) for E3,E2 385694 1 *
6 9H3 0001 442 BASE BOARD (JP) for JP 391446 1 *
7 9H3 0001 013 FOOT 382222 4
8 9H3 0001 399 MOLD CASE A3L8A0 385473 1 *
9 9H3 0000 724 BRKT PCB C A3B1A0 077876 4
10 9H3 0000 709 BRKT TRANS A3H6A0 046984 1
11 9H3 0001 453 PANEL REAR (E3) A3L8B0-3 for E3 391181 1 *
11 9H3 0001 459 PANEL REAR (E2) A3L8C0-3 for E2 391182 1 *
11 9H3 0001 402 PANEL REAR (JP) A3L8A0-3 for JP 391180 1 *
! 12 9H3 0001 018 SW ROCKER JW-M11RKK 058288 1
13 9H3 0001 396 KNOB VR A181B0 330507 2 *
! 14 9H3 0001 451 CORD AC (E3) 2.0M WITH 51067 LF for E3 388158 1 *
! 14 9H3 0001 457 CORD AC (E2) 2.0M WITH 51067 LF for E2 388160 1 *
! 14 9H3 0001 019 CORD AC (JP) HVFF 0.75*2 3.0M LF for JP 379699 1
15 9H3 0000 711 CUSHION STOPPER SR-4K 4 078519 1
16 - HEATSINK MAIN A3L8A0 385474 1
17 9H3 0001 401 COVER HEATSINK A3L8A0-2 387692 1 *
18 9H3 0001 407 BRKT PWB A A3J8A0 335414 1 *
19 9H3 0001 408 BRKT PWB B A3J8A0 335415 1 *
! 20 9H3 0001 454 TRANS POWER (E3) A3L8B0 for E3 388159 1 *
! 20 9H3 0001 460 TRANS POWER (E2) A3L8C0 for E2 388161 1 *
! 20 9H3 0001 400 TRANS POWER (JP) A3L8A0 for JP 386258 1 *
SCREWS
101 9H3 0000 738 SC BD 4*25 BL 021387 10
102 9H3 0001 446 SC BD 4*30 BL 021389 4 *
103 9H3 0001 445 SC BD 5*65 BL 387950 4 *
104 9H3 0000 734 SC PN S-F T-B 3*8 ZC 075164 12
105 9H3 0001 436 SC BD T-B 3*8 BL BOSS 075243 2 *
106 9H3 0001 437 SC PN T-B 3*12 BL 075512 6 *
107 9H3 0001 028 SC BD T-B 3*10 BL 075640 14
108 9H3 0000 736 SC BD T-B 4*10 BL 075659 8
109 9H3 0000 737 SC PN S-W M3*12 BL 075461 3
