Residual risks
• In spite of the application of the relevant
safety regulations and the implementation of
safety devices, certain residual risks cannot be
avoided.
These are:
– Impairment of hearing.
– Risk of dust inhalation.
– Risk of personal injury due to prolonged use.
– Risk of burns due to accessories becoming
hot during operation.
TORQUE LIMITING CLUTCH
All rotary hammer drills are equipped with a torque
limiting clutch that reduces the maximum torque
reaction transmitted to the operator in case of
jamming of a drill bit. This feature also prevents the
gearing and electric motor from stalling. The torque
limiting clutch has been factory-set and cannot be
adjusted.
Electrical safety
The electric motor has been designed for one
voltage only. Always check that the power supply
corresponds to the voltage on the rating plate.
Your DEWALT tool is double insulated in
accordance with EN 60745; therefore no
earth wire is required.
In case of cord replacement the tool must only be
repaired by an authorized service agent or by
qualified electrician.
Using an extension cable
If an extension cable is required, use an approved
extension cable suitable for the power input of this
tool (see technical data). The minimum conductor
size is 1.5 mm
2
.
When using a cable reel, always unwind the cable
completely. Also refer to the following table.
Conductor size (mm
2
) Cable rating (Amperes)
0.75 6
1.00 10
1.50 15
2.50 20
4.00 25
Cable length (m)
7.5 15 25 30 45 60
Voltage Amperes Cable rating (Amperes)
230 0 – 2.0 6 6 6 6 6 6
2.1 – 3.4 6 6 6 6 6 6
3.5 – 5.0 6 6 6 6 10 15
5.1 – 7.0 10 10 10 10 15 15
7.1 – 12.0 15 15 15 15 20 20
12.1 – 20.0 20 20 20 20 25 –
ASSEMBLY AND ADJUSTMENT
WARNING: Prior to assembly and
adjustment always unplug the tool.
Selecting the operating mode
(fi g. B1, B2)
D25102(K) (FIG. B1)
The tool can be used in the following operating
modes:
Rotary drilling: for screwdriving
and for drilling into steel, wood
and plastics
Hammer drilling: for concrete
and masonry drilling
operations.
D25103K/D25104K/D25203K (FIG. B2)
The tool can be used in the following operating
modes:
Rotary drilling: for screwdriving
and for drilling into steel, wood
and plastics
Hammer drilling: for concrete
and masonry drilling
operations.
Hammering only: for light
chipping, chiselling and
demolition applications
In this mode the tool can also
be used as a lever to free a
jammed drill bit.
Bit rotation: non-working
position used only to rotate
a flat chisel into the desired
position.
• To select the operating mode, press the safety
lock (5) and rotate the mode selector switch
(4) until it points to the symbol of the required
mode.
