DeWalt D25614 User Manual

8
ENGLISH
Proper Hand Position (Fig.D)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.

WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the side handle
13
,
with the other hand on the main handle
4
.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicableregulations.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
SDS plus® and SDS max® are registered trademarks of
RobertBoschGmbH.
Bit and Bit Holder

WARNING: Burn Hazard. ALWAYS wear gloves when
changing bits. Accessible metal parts on the tool and bits
may get extremely hot during operation. Small bits of
broken material may damage barehands.
The rotary hammer can be fitted with various drill and chisel
bits. depending on the desired application. Use sharp drill and
chisel bitsonly.
Inserting and Removing SDSmax® Accessories
(Fig.C)
This machine uses SDSmax® bits and chisels (refer to the inset
in FigureD for a cross-section of an SDSmax® bitshank).
1. Clean the bitshank.
2. Pull back the locking sleeve
6
and insert the bitshank.
3. Release the locking sleeve and turn the bit slightly until the
sleeve snaps intoposition.
4. Pull on the bit to check if it is properly locked. The
hammering function requires the bit to be able to move
axially several centimetres when locked in the bitholder.
5. To remove a bit pull back the bit holder locking sleeve/
collar
6
and pull the bit out of the bit holder
5
.
2. Slide the assembly onto the nose of the tool, through the
steel ring
14
and onto the collar
2
, past the chisel holder
andsleeve.
3. Rotate the side handle assembly to the desired position. For
hammerdrilling horizontally with a heavy drill bit, place the
side handle assembly at an angle of approximately 20° to
the tool for optimumcontrol.
4. Lock the side handle mounting assembly in place by
securely tightening the handle
13
rotating it clockwise so
that the assembly will notrotate.
Operation Modes (Fig.A)

WARNING: Do not select the operating mode when the
tool isrunning.

CAUTION: Never use in Rotary Drilling or Rotary
Hammering mode with a chisel bit in the bit holder.
Personal injury and damage to the the tool mayresult.
Your tool is equipped with a mode selector dial
3
to selectthe
mode appropriate to desiredoperation.
Symbol Mode Application
Rotary
Hammering
Drilling into concrete
andmasonry
Hammering only Lightchipping
Bit Adjustment Chisel bit position adjustment
To Select an Operating Mode
• Rotate the mode selector switch so that the arrow points to
the symbol corresponding for the desiredmode.
NOTE: The arrow on the mode selector switch
3
must be
pointing at a mode symbol at all times. There are no operable
positions inbetween. It may be necessary to briefly run the
motor after having changed from 'hammering only' to 'rotary'
modes in order to align thegears.
Indexing the Chisel Position (Fig.A)
The chisel can be indexed and locked into 18differentpositions.
1. Rotate the mode selector switch
3
until it points towards
the position.
2. Rotate the chisel to the desiredposition.
3. Set the mode selector switch
3
to the “hammering
only”position.
4. Twist the chisel until it locks inposition.
Performing an Application (Fig.A)

WARNING: TO REDUCE THE RISK OF PERSONAL
INJURY, ALWAYS ensure workpiece is anchored or
clamped firmly. If drilling thin material, use a wood
“backup” block to prevent damage to thematerial.
Switching On and Off (Fig.A)
To turn the tool on, depress the trigger switch
1
.
To stop the tool, release the triggerswitch.
Drilling with a Solid Bit (Fig.A)
1. Insert the appropriate drillbit.
2. Set the mode selector switch
3
to the
hammerdrillingposition.
3. Set the electronic speed and impact control dial
8
.
4. Fit and adjust the side handle
13
.
5. Mark the spot where the hole is to bedrilled.
6. Place the drill bit on the spot and switch on thetool.
7. Always switch off the tool when work is finished and
beforeunplugging.
