COMPONENTS (Fig. 2, 5, 6)
WARNING: Never modify the power tool or any part of it. Damage
or personal injury could result.
A. Trigger switch H. Hog ring
B. Rocker switch (DW059) I. Battery release buttons
C. Forward/reverse button J. Worklight
D. Chuck collar K. Belt hook (optional
E. 1/4" hex quick-release chuck accessory
F. Detent pin L. Belt hook screw
G. Anvil M. Battery
INTENDED USE
These heavy-duty impact wrench/drivers are designed for professional
impact screwdriving applications. The impact function makes this tool
particularly useful for driving fasteners in wood, metal and concrete.
DO NOT use under wet conditions or in presence of flammable
liquids or gases.
These heavy-duty impact wrench/drivers are professional power tools.
DO NOT let children come into contact with the tool. Supervision is
required when inexperienced operators use this tool.
BELT HOOK (OPTIONAL ACCESSORY)
WARNING: To reduce the risk of serious personal injury, DO
NOT suspend tool overhead or suspend objects from the belt hook.
ONLY hang tool’s belt hook from a work belt.
WARNING: To reduce the risk of serious personal injury,
ensure the screw (L) holding the belt hook is secure.
The belt hook (K) can be be attached to either side of the tool to
accommodate left- or right- handed users. If the hook is not desired
at all, it can be removed from the tool.
FIG. 2
C
D
A
I
E
J
K
L
M
B
G
DW059
English
10
