ENGLISH
10
1. Remove the high-pressure hose
10
from its
storagechannel.
2. Attach a nozzle as described in the Fitting the
Accessories section. Attach the chuck to the tire stem
to inflate a tire, or attach an accessory to inflate a ball or
otherinflatable.
3. Attach or insert the nozzle into the object beinginflated.
4. Press the power switch
2
. The inflator will default to
High-Pressure inflation mode.
NOTE: The pressure gauge display
9
will only show
inflation pressures when the inflator is in high-
pressuremode.
NOTE: To switch between pressure units, press and hold
the inflation mode switch
3
and the LED light switch
4
while rotating the pressure adjustment knob
6
.
5. Rotate the pressure adjustment knob
6
to set the
desiredpressure.
6. Press the inflation start/pause button
7
to
begininflation.
7. To stop the inflator at any time, press the inflation start/
pause button
7
.
8. When the item to be inflated has reached the preset
value, the unit will automatically turnoff.
NOTE: You may notice the actual pressure reading may
drop after a couple of seconds. This isnormal.
NOTE: If the power switch
2
is turned off, all settings will
be lost and will need to be reentered. This is a safety feature
to prevent the risk of items OVERINFLATING.
Using the Inflator as a Pressure Gauge
1. Connect the high-pressure hose
10
to the item to
bechecked.
2. Press the power switch
2
.
3. The pressure gauge display
9
will display the
item'spressure.
MAINTENANCE

WARNING: To reduce the risk of serious personal
injury, turn unit off, remove the battery pack
and disconnect it from the power source before
making any adjustments or removing/installing
attachments or accessories. An accidental start-up
can causeinjury.
Storage Recommendations
Store the inflator indoors. The best storage place is one that
is cool and dry, away from direct sunlight and excess heat
orcold.
Lubrication
This unit requires no additionallubrication.
Cleaning

WARNING: Blow dirt and dust out of all air vents with
clean, dry air at least once a week. To minimize the risk
of eye injury, always wear ANSI Z87.1 approved eye
protection when performingthis.

WARNING: Never use solvents or other harsh
chemicals for cleaning the non-metallic parts of
the tool. These chemicals may weaken the plastic
materials used in these parts. Use a cloth dampened
only with water and mild soap. Never let any liquid
get inside the tool; never immerse any part of the tool
into aliquid.
Accessories

WARNING: Since accessories, other than those
offered by
DeWALT
, have not been tested with this
product, use of such accessories with this tool could be
hazardous. To reduce the risk of injury, only
DeWALT
recommended accessories should be used with
thisproduct.
Recommended accessories for use with your tool
are available at extra cost from your local dealer or
authorized service center. If you need assistance in
locating any accessory, please contact
DeWALT
Industrial
Tool Co., 701East Joppa Road, Towson, MD 21286, call
1-800-4-
DeWALT
(1-800-433-9258) or visit our website:
www.dewalt.com.
Repairs
The charger, battery pack and external power supply are
notserviceable. If the inflator will not turn on, check the
battery, all connections, and the fuse in the 12V DC vehicle
connector
19
. The inflator display will show an error code
under certain conditions. Refer to the Troubleshooting
Error Codeschart.

WARNING: To assure product SAFETY and
RELIABILITY, repairs, maintenance and adjustment
(including brush inspection and replacement, when
applicable) should be performed by a
DeWALT
factory
service center or a
DeWALT
authorized service center.
Always use identical replacementparts.
Register Online
Thank you for your purchase. Register your product nowfor:
• WARRANTY SERVICE: Registering your product will
help you obtain more efficient warranty service in case
there is a problem with yourproduct.
• CONFIRMATION OF OWNERSHIP: In case of
an insurance loss, such as fire, flood or theft, your
registration of ownership will serve as your proof
ofpurchase.
• FOR YOUR SAFETY: Registering your product will
allow us to contact you in the unlikely event a safety
notification is required under the Federal Consumer
SafetyAct.
Register online at www.dewalt.com/register.
Three Year Limited Warranty
DeWALT
will repair, without charge, any defects due to
faulty materials or workmanship for three years from
the date of purchase. This warranty does not cover part
failure due to normal wear or tool abuse. For further detail
of warranty coverage and warranty repair information,
visit www.dewalt.com or call 1-800-4-
DeWALT
(1-800-
