DANGER: Indicates an imminently
hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING: Indicates a potentially
hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION: Indicates a potentially
hazardous situation which, if not avoided,
may result in minor or moderate
injury.
Fuses:
Europe 230V tools 10 Amperes, mains
U.K. & Ireland 230V tools 3 Amperes, in plugs
Definitions: Safety Guidelines
The definitions below describe the level of severity
for each signal word. Please read the manual and
pay attention to these symbols.
The vibration emission level given in this information
sheet has been measured in accordance with a
standardised test given in EN60745 and may be
used to compare one tool with another. It may be
used for a preliminary assessment of exposure.
WARNING: The declared vibration
emission level represents the main
applications of the tool. However if the
tool is used for different applications,
with different accessories or poorly
maintained, the vibration emission may
differ. This may significantly increase the
exposure level over the total working
period.
Battery pack DCB180 DCB181 DCB182 DCB183/B DCB184/B DCB185
Battery type Li-Ion Li-Ion Li-Ion Li-Ion Li-Ion Li-Ion
Voltage V
DC
18 18 18 18 18 18
Capacity Ah 3.0 1.5 4.0 2.0 5.0 1.3
Weight kg 0.64 0.35 0.61 0.40/0.45 0.62/0.67 0.35
Charger DCB105
Mains voltage V
AC
230
Battery type 10.8/14.4/18 Li-Ion
Approx. charging time of
battery packs
min
25 (1.3 Ah)
55 (3.0 Ah)
30 (1.5 Ah)
70 (4.0 Ah)
40 (2.0 Ah)
90 (5.0 Ah)
Weight kg 0.49
Charger DCB107 DCB112
Mains voltage V
AC
230 230
Battery type 10.8/14.4/18 Li-Ion 10.8/14.4/18 Li-Ion
Approx. charging time of
battery packs
min 60 (1.3 Ah) 70 (1.5 Ah) 90 (2.0 Ah) 40 (1.3 Ah) 45 (1.5 Ah) 60 (2.0 Ah)
140 (3.0 Ah) 185 (4.0 Ah) 240 (5.0 Ah) 90 (3.0 Ah) 120 (4.0 Ah) 150 (5.0 Ah)
Weight kg 0.29 0.36
Charger DCB113 DCB115
Mains voltage V
AC
230 230
Battery type 10.8/14.4/18 Li-Ion 10.8/14.4/18 Li-Ion
Approx. charging time of
battery packs
min 30 (1.3 Ah) 35 (1.5 Ah) 50 (2.0 Ah) 25 (1.3 Ah) 30 (1.5 Ah) 40 (2.0 Ah)
70 (3.0 Ah) 100 (4.0 Ah) 120 (5.0 Ah) 55 (3.0 Ah) 70 (4.0 Ah) 90 (5.0 Ah)
Weight kg 0.4 0.5
An estimation of the level of exposure to
vibration should also take into account
the times when the tool is switched off or
when it is running but not actually doing
the job. This may significantly reduce
the exposure level over the total working
period.
Identify additional safety measures to
protect the operator from the effects of
vibration such as: maintain the tool and
the accessories, keep the hands warm,
organisation of work patterns.
