DeWalt DCE089G User Manual

7
E
• Do not use optical tools such as a telescope or transit
to view the laser beam. Serious eye injury could result.
• Do not place the laser in a position which may cause
anyone to intentionally or unintentionally stare into the
laser beam. Serious eye injury could result.
• Do not position the laser near a reective surface which
may reect the laser beam toward anyone’s eyes.
Serious eye injury could result.
• Turn the laser off when it is not in use. Leaving the laser
on increases the risk of staring into the laser beam.
• Do not modify the laser in any way. Modifying the tool
may result in hazardous laser radiation exposure.
• Do not operate the laser around children or allow
children to operate the laser. Serious eye injury may
result.
• Do not remove or deface warning labels. If labels
are removed user or others may inadvertently expose
themselves to radiation.
• Position the laser securely on a level surface. Damage
to the laser or serious injury could result if the laser falls.
Laser Information
• The DCE089G, DCE089R 3-Beam 360° Line Laser and
the DCE0811G, DCE0811R 2-Beam 360° Line Laser are
Class 2 laser products. The lasers are self-leveling laser
tools that can be used for horizontal (level) and vertical
(plumb) alignment projects.
WARNING:
Read and understand all instructions. Failure to
follow all instructions listed below may result in electric
shock, re and/or serious personal injury.
Work Area
• Keep your work area clean and well lit. Cluttered benches
and dark areas invite accidents.
• Do not operate laser tools in explosive atmospheres, such
as in the presence of ammable liquids, gases, or dust.
• Keep children and bystanders away while operating a laser
tool. Distractions can cause you to lose control.
Electrical Safety
• Use battery operated tool only with the specically
designed batteries. Use of any other batteries may create
a risk of re.
• Product Overview
WARNING:
Never modify the tool or any part of it. Damage to the
laser or personal injury could result.
Figure 2 - Battery Interface
A
Figure 1A - Pendulum Lock
B
Figure 1B - Keypad
C
Figure 1B - ON/OFF button: horizontal laser line
D
Figure 1B - ON/OFF button: side laser line
E
Figure 1B - ON/OFF button: front vertical laser line
(DCE089R/G only)
F
Figure 2 - Magnetic pivot bracket
G
Figure 4 - Tripod thread tting (1/4 - 20 & 5/8 -11)
I
Figure 1B - Battery level indicator
J
Figure 5 - Ceiling Mount Clamp
K
Figure 5 - Ceiling Mount
L
Figure 5 - Screw Hole
M
Batteries and Power
• This tool is powered by the following DEWALT 12V
Max Battery packs: DCB120, DCB127 or may also be
powered using the DEWALT AA Starter pack which
can carry 4 x AA batteries. Note: The AA starter pack is
recommended only for use with the red laser.
Battery Installation / Removal
Using the AA Starter Pack:
CAUTION:
The AA starter pack is designed specically for use
only with the DEWALT 12V Max compatible laser
products and cannot be used with any other tools Do
not attempty to modify the product.
