ENGLISH
3
EC-Declaration of Conformity
Machinery Directive and Radio Equipment
Directive
Heavy-Duty Cordless SDSmax® Combination
Hammer
DCH735, DCH775
DeWALT declares that these products described under Technical
Data are in compliance with:
2006/42/EC, EN62841-1:2015+A11:2022, EN IEC 62841-2-6:2020
+ A11:2020.
These products also comply with Directive 2014/53/EU and
2011/65/EU. For more information, please contact DeWALT at
the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf ofDeWALT.
Markus Rompel
Vice-President Engineering, PTE-Europe
DeWALT, Richard-Klinger-Straße 11,
65510, Idstein, Germany
30.12.2022
DECLARATION OF CONFORMITY
THE SUPPLY OF MACHINERY SAFETY
REGULATIONS 2008
Heavy-Duty Cordless SDSmax®
Combination Hammer
DCH735, DCH775
DeWALT declares that these products described under Technical
Data are in compliancewith:
The Supply of Machinery (Safety) Regulations, 2008, S.I.
2008/1597 (as amended),
An estimation of the level of exposure to vibration and/or
noise should also take into account the times when the tool is
switched off or when it is running but not actually doing the
job. This may significantly reduce the exposure level over the
total workingperiod.
Identify additional safety measures to protect the operator
from the effects of vibration and/or noise such as: maintain
the tool and the accessories, keep the hands warm (relevant
for vibration), organisation of workpatterns.
The vibration and/or noise emission level given in this information
sheet has been measured in accordance with a standardised test
given in EN IEC 62841 and may be used to compare one tool with
another. It may be used for a preliminary assessment ofexposure.

WARNING: The declared vibration and/or noise emission
level represents the main applications of the tool. However,
if the tool is used for different applications, with different
accessories or is poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase the
exposure level over the total workingperiod.
DCH735 DCH775
Voltage V
DC
54 54
Type 1 1
No-load speed min
-1
177–355 145–290
No-load beats per minute bpm 1350–2705 1105–2210
Single impact energy (EPTA 05/2009) J 13.3 19.4
Optimum drilling range into concrete mm 25–38 28–42
Maximum drilling range in concrete mm 48 52
Maximum core drilling range in
concrete
mm 40–125 40–150
Bit holder SDS max® SDS max®
Chisel positions 24 24
Wireless Tool Control Transmitter
Frequency Band
Max. Power (EIRP)
MHz
mW
433
0.03
433
0.03
Weight (without battery pack) kg 8.5 9.4
Noise values and vibration values (triax vector sum) according to EN IEC 62841-2-6:
L
PA
(emission sound pressure level) dB(A) 99 99
L
WA
(sound power level) dB(A) 107 107
K (uncertainty for the given
sound level)
dB(A) 3 3
Drilling
Vibration emission value a
h, HD
= m/s² 8.8 13.5
Uncertainty K = m/s² 1.5 1.5
Chiselling
Vibration emission value a
h
, Cheq
= m/s² 9.5 10.8
Uncertainty K = m/s² 1.5 1.5
* Measured at the side handle. Side handle vibration is higher than vibration at
the main handle.
Congratulations!
You have chosen a DeWALT tool. Years of experience, thorough
product development and innovation make DeWALT one of the
most reliable partners for professional power toolusers.
Technical Data
English (original instructions)
HEAVY‑DUTY CORDLESS SDSMAX COMBINATION HAMMER
DCH735, DCH775
