10
English
Do not charge damaged battery packs.
Do not expose to water.
Have defective cords replaced immediately.
Charge only between 4 ˚C and 40 ˚C.
Only for indoor use.
Discard the battery pack with due care for the
environment.
Charge
DeWALT
battery packs only with
designated
DeWALT
chargers. Charging
battery packs other than the designated
DeWALT
batteries with a
DeWALT
charger may
make them burst or lead to other dangerous
situations.
Do not incinerate the battery pack.
Battery Type
The DCM571 operates on a 54 volt battery pack.
These battery packs may be used: DCB546, DCB547. Refer to
Technical Data for moreinformation.
Package Contents
The package contains:
1 String trimmer
1 Auxiliary handle
4 Auxiliary handle screws
1 Strap
1 Guard
4 Guard screws
1 Brush cutter blade
1 Brush cutter nut
1 Brush cutter clamp washer
1 Brush cutter drive washer
5 Cotter pins
1 Nut wrench
1 Rod, lock
1 Blade cover
1 Battery (not for DCM571N)
1 Charger (not for DCM571N)
1 Instruction manual
• Check for damage to the tool, parts or accessories which
may have occurred duringtransport.
Transporting the FLEXVOLT
TM
Battery
The
DeWALT
FLEXVOLT
TM
battery has two modes: Use and
Transport.
Use Mode: When the FLEXVOLT
TM
battery stands alone or is
in a
DeWALT
18V product, it will operate as an 18V battery.
When the FLEXVOLT
TM
battery is in a 54V or a 108V (two 54V
batteries) product, it will operate as a 54V battery.
Transport Mode: When the cap is attached to the
FLEXVOLT
TM
battery, the battery is in Transport mode. Keep
the cap for shipping.
When in Transport mode,
strings of cells are electrically
disconnected within the
pack resulting in 3 batteries
with a lower Watt hour (Wh) rating as compared to 1 battery
with a higher Watt hour rating. This increased quantity of 3
batteries with the lower Watt hour rating can exempt the
pack from certain shipping regulations that are imposed
upon the higher Watt hour batteries.
For example, the
Transport Wh rating
might indicate 3x36
Wh, meaning 3
batteries of 36 Wh each.
The Use Wh rating might indicate 108Wh (1battery implied).
Storage Recommendations
1. The best storage place is one that is cool and dry
away from direct sunlight and excess heat or cold. For
optimum battery performance and life, store battery
packs at room temperature when not in use.
2. For long storage, it is recommended to store a fully
charged battery pack in a cool, dry place out of the
charger for optimal results.
NOTE: Battery packs should not be stored completely
depleted of charge. The battery pack will need to be
recharged before use.
Labels on Charger and Battery Pack
In addition to the pictographs used in this manual, the labels
on the charger and the battery pack may show the following
pictographs:
Read instruction manual before use.
See Technical Data for charging time.
Do not probe with conductive objects.
Example of Use and Transport Label Marking

DeWalt DCM571 Specifications

General

Type	Brush cutter
Cordless	Yes
Head type	Nylon line
Handle type	U-type handle
Line diameter	2 mm
Product color	Black, Yellow
Rotational speed	6600 RPM
Sound power level	94 dB
Vibration emission	1.5 m/s²
Sound pressure level	74 dB
Cutting diameter (max)	380 mm
Power source	Battery
Charging time	1.16 h
Battery voltage	54 V
Battery capacity	3 Ah

Weight and Dimensions

Weight	4600 g
