DeWalt DCMPS567 User Manual

15
ENGLISH
2. Insert battery pack into the charger as described in the
charger section of thismanual.
Fuel Gauge Battery Packs (Fig. B)
Some DeWALT battery packs include a fuel gauge which consists
of three green LED lights that indicate the level of charge
remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge
button
27
. A combination of the three green LED lights will
illuminate designating the level of charge left. When the level of
charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-userapplication.
Installing and Removing Saw Chain
(Fig. A, C–E)

WARNING: Sharp moving blade. To prevent accidental
operation, insure that battery is disconnected from the
handle before performing the following operations. Failure
to do this could result in serious personal injury.

CAUTION: Sharp moving blade. Always wear protective
gloves when installing or removing the chain. The chain is
sharp and can cut you when it is not running.
1. Place the pole saw on a firm surface. Rotate the two hex
head screws
12
counterclockwise with the hex wrench 
16
provided.
2. Remove sprocket cover
11
, bar clamp
10
, and hex
headscrews.
3. To remove the saw chain
14
, rotate the screw
20
in the
front of the housing using the flat screwdriver end of the
wrench. Turning the screw counterclockwise allows the
guide bar
13
to recede and reduces the tension on the
chain so that it may beremoved.
4. Lift the worn saw chain out of the groove in the guidebar.
5. Flip guide bar over.
6. To replace the saw chain, check to make sure that the slot in
the guide bar is over the location pins
21
shown in Fig.E and
that hole below the slot is located over the adjustment pin.
7. Place new chain in groove of guide bar and around
sprocket. Make sure saw teeth are facing correct direction by
matching the graphic onhousing or guidebar.
8. Rotate the screw in the front of the housing clockwise to
increase the chain tension.
9. Replace sprocket cover, bar clamp, and hex headscrews.
10. Follow the instructions in the section Adjusting
ChainTension.
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.

WARNING:Use only DeWALT battery packs andchargers.
Description (Fig. A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Handle assembly
2
Center extension pole
3
Saw head assembly
4
Trigger switch
5
Lock button
6
Battery
7
Foam gripper
8
Threaded pole
9
Threaded sleeve
10
Bar clamp
11
Sprocket cover
12
Hex head screws
13
Guide bar
14
Saw chain
15
Scabbard
16
Hex wrench
17
Oil cap
18
Branch removal hook
19
Strap mount
Intended Use
This pole saw is ideal for pruning applications and cutting limbs
up to 203 mm indiameter.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
This pole saw is a professional power tool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
without supervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
Inserting and Removing the Battery Pack
from the Tool (Fig. B)
NOTE: Make sure your battery pack
1
is fullycharged.
To Install the Battery Pack into the Tool Handle
1. Align the battery pack
1
with the rails inside the tool’s
handle (Fig. B).
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap intoplace.
To Remove the Battery Pack from the Tool
1. Press the release button
24
and firmly pull the battery pack
out of the toolhandle.

DeWalt DCMPS567 Specifications

General

Chain speed	6.5 m/s
Product color	Black, Yellow
Chain bar length	200 mm
Oil tank capacity	0.115 L
Power source	Battery
Battery voltage	18 V

Weight and Dimensions

Weight	3800 g
Bar length	3000 mm
Length (max)	4500 mm
Adjustable length	Yes
