14
ENGLISH
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-userapplication.
Trigger Switch (Fig. A)

WARNING: This tool has no provision to lock the trigger
switch in the ON position and should never be locked ON
by any other means.
The saw is controlled by a trigger switch
1
and lock-off button
2
. The lock-off button must be pressed before the trigger
switch will turn the saw on. Releasing the trigger turns the
sawoff.
Changing Blades (Fig. A, E–G)
To Install the Blade
1. Place inner clamp washer
17
on saw spindle
19
with the
large flat surface facing out toward the blade (Fig.E,F).
2. Retract the lower blade guard
7
and place blade
20
on
saw spindle against the inner clamp washer
17
, making
sure that the blade will rotate in the proper direction (the
direction of the rotation arrow on the saw blade and the
teeth must point in the same direction as the direction of
rotation arrow on the saw). Do not assume that the printing
on the blade will always be facing you when properly
installed. When retracting the lower blade guard to install
the blade, check the condition and operation of the lower
blade guard to assure that it is working properly. Make sure
it moves freely and does not touch the blade or any other
part, in all angles and depths of cut.
3. Place the outer clamp washer
18
on the saw spindle
19
with the large flat surface against the blade
20
with
beveled side facing out.
4. Thread the blade clamping screw
6
into the saw spindle
by hand. (Screw has left-hand threads and must be turned
counterclockwise to tighten. Refer to arrow in FigureGA.)
5. Depress the spindle lock button
4
while turning the saw
spindle with the hex key (
12
, Fig.A) until the spindle lock
engages and the blade stops rotating.
6. Tighten the blade clamping screw firmly with the hex key.
NOTICE: Never engage the spindle lock while saw is
running, or engage in an effort to stop the tool. Never
turn the saw on while the spindle lock is engaged. Serious
damage to your saw will result.
To Replace the Blade
1. To loosen the blade clamping screw
6
, depress the spindle
lock button
4
and turn the saw spindle
19
with the hex
key
12
until the spindle lock engages and the blade stops
rotating. With the spindle lock engaged, turn the blade
clamping screw clockwise with the hex key. (Screw has left-
hand threads and must be turned clockwise to loosen. Refer
to arrow in FigureGB.)
2. Remove the blade clamping screw
6
and outer clamp
washer
18
only. Remove old blade.
3. Clean any metal chips/shavings that may have accumulated
in the guard or clamp washer area and check the condition
and operation of the lower blade guard as previously
outlined. Do not lubricate this area.
4. Select the proper blade for the application (see Blades).
Always use blades that are the correct size (diameter)
with the proper size and shape centre hole for mounting
on the saw spindle. Always assure that the maximum
recommended speed (rpm) on the saw blade meets or
exceeds the speed (rpm) of the saw.
5. Follow steps 2 through 6 under To Install the Blade, making
sure that the blade will rotate in the properdirection.
Lower Blade Guard

WARNING: Under certain conditions of use, metal chips
may become imbedded in the surfaces of the lower guard,
causing the lower guard to rub against the upper guard.
Check the operation of the lower guard before each use
and remove any imbedded chips.

WARNING: The lower blade guard is a safety feature
which reduces the risk of serious personal injury.
Never use the saw if the lower guard is missing,
damaged, misassembled or not working properly.
Do not rely on the lower blade guard to protect
you under all circumstances. Your safety depends
on following all warnings and precautions as well
as proper operation of the saw. Check lower guard
for proper closing before each use as outlined
in Additional Safety Rules for Circular Saws. If
the lower blade guard is missing or not working
properly, have the saw serviced before using.
To assure product safety and reliability, repair,
maintenance and adjustment should be performed
by an authorised service centre or other qualified
service organization, always using identical
replacementparts.
Blades

WARNING: To minimise the risk of eye injury, always
use eye protection. Carbide is a hard but brittle material.
Foreign objects in the workpiece such as wire or nails
can cause tips to crack or break. Only operate saw when
proper saw blade guard is in place. Mount blade securely
in proper rotation before using, and always use a clean,
sharp blade.
Blade Diameter Teeth Application
DT1212-QZ 140 mm 30 General purpose ferrous
metal cutting
If you need assistance regarding blades, please contact your
local D
eWALT dealer.
Kickback
Kickback is a sudden reaction to a pinched, bound or misaligned
saw blade, causing an uncontrolled saw to lift up and out of the
workpiece toward the operator. When the blade is pinched or
bound tightly by the kerf closing down, the blade stalls and the
motor reaction drives the unit rapidly back toward the operator.
