30
ENGLISH
Battery pack DCB546
Battery type Li-Ion
Voltage V
DC
18/54
Capacity Ah 6.0/2.0
Weight kg 1.05
Charger DCB118
Mains voltage V
AC
230
Battery type 18/54 Li-Ion
Approx. charging time of
battery packs
min 22 (1.3 Ah) 22 (1.5 Ah) 30 (2.0 Ah)
45 (3.0 Ah) 60 (4.0 Ah) 75 (5.0 Ah)
60 (6.0 Ah)
Weight kg 0,66
The DCB118 charger accepts 18V Li-Ion XR and XRFLEXVOLT
TM
battery packs (DCB181, DCB182, DCB183, DCB183B, DCB184,
DCB184B, DCB185 and DCB546).
Fuses:
Europe 230V tools 10 Amperes. mains
U.K. & Ireland 230V tools 3 Amperes. in plugs
EC-Declaration of Conformity
Machinery Directive
Cordless Plunge Saw
DCS520
declares that these products described under
Technical Data are in compliance with:
2006/42/EC, EN60745-1:2009+A11:2010, EN60745-2-5:2010.
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact
at
the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf of
.
Markus Rompel
Director Engineering
, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
29.07.2016
WARNING: To reduce the risk of injury, read the
instruction manual.
English (original instructions)
CORDLESS PLUNGE SAW
DCS520
Congratulations!
You have chosen a
tool. Years of experience, thorough
product development and innovation make
one of the
most reliable partners for professional power toolusers.
Technical Data
DCS520
Voltage V
DC
54
Type 1
Battery type Li-Ion
No-load speed min
-1
2500–4200
Blade diameter mm 165
Maximum depth of cut
90° (without guide rail)
90° (with guide rail)
mm
mm
59
55
Blade bore mm 20
Bevel angle adjustment 47°
Weight (without battery pack) kg 4.7
Noise values and vibration values (triax vector sum) according to EN60745-2-5:
L
PA
(emission sound pressure level) dB(A) 82.2
L
WA
(sound power level) dB(A) 93.2
K (uncertainty for the given sound level) dB(A) 2.9
Vibration emission value a
h
= m/s
2
1.1
Uncertainty K = m/s
2
1.5
The vibration emission level given in this information sheet has
been measured in accordance with a standardised test given in
EN60745 and may be used to compare one tool with another. It
may be used for a preliminary assessment ofexposure.
WARNING: The declared vibration emission level
represents the main applications of the tool. However if
the tool is used for different applications, with different
accessories or poorly maintained, the vibration emission
may differ. This may significantly increase the exposure
level over the total workingperiod.
An estimation of the level of exposure to vibration should
also take into account the times when the tool is switched
off or when it is running but not actually doing the job.
This may significantly reduce the exposure level over the
total workingperiod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool
and the accessories, keep the hands warm, organisation
of workpatterns.
