ENGLISH
English (original instructions)
CORDLESS COMPACT MITRE SAW
DCS777
Congratulations!
You have chosen a DeWALT tool. Years of experience, thorough product development and innovation make DeWALT one of the most reliable partners for
professional power toolusers.
Technical Data
DCS777
Voltage V
DC
54 (60 Max)
XPS Yes
Power output W 1750
Blade diameter mm 216
Blade bore mm 25.4/30
Max. blade speed min
-1
6300
Mitre (max. positions) left and right 50°
Bevel (max. positions) left 48°
Compound mitre bevel 45°
mitre 45°
Capacities
cross-cut 90° mm 60 x 270
mitre 45° mm 60 x 190
mitre 50° mm 60 x 170
bevel 45° mm 48 x 270
bevel 48° mm 45 x 270
Overall dimensions mm 460 x 560 x 430
Weight kg 15.0
WARNING: To reduce the risk of injury, read the instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each signal word.
Please read the manual and pay attention to thesesymbols.

DANGER: Indicates an imminently hazardous situation which, if not
avoided, will result in death or seriousinjury.

WARNING: Indicates a potentially hazardous situation which, if not
avoided, could result in death or seriousinjury.

CAUTION: Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderateinjury.
NOTICE: Indicates a practice not related to personal injury which,
if not avoided, may result in propertydamage.
Batteries Chargers/Charger Times (Minutes)
Cat# V Ah (kg)
DCB104 DCB107 DCB112 DCB113 DCB115 DCB118 DCB132 DCB119
DCB546 18/54 6.0/2.0 1.05 60 270 170 140 90 60 90 X
DCB547 18/54 9.0/3.0 1.46 75* 420 270 220 135* 75* 135* X
DCB548 18/54 12.0/4.0 1.44 120 540 350 300 180 120 180 X
DCB181 18 1.5 0.35 22 70 45 35 22 22 22 45
DCB182 18 4.0 0.61 60/40** 185 120 100 60 60/40** 60 120
DCB183/B 18 2.0 0.40 30 90 60 50 30 30 30 60
DCB184/B 18 5.0 0.62 75/50** 240 150 120 75 75/50** 75 150
DCB185 18 1.3 0.35 22 60 40 30 22 22 22 X
DCB187 18 3.0 0.54 45 140 90 70 45 45 45 90
DCB189 18 4.0 0.54 60 185 120 100 60 60 60 120

Denotes risk of electricshock.

Denotes risk offire.
GENERAL POWER TOOL SAFETY WARNINGS

WARNING: Read all safety warnings, instructions, illustrations
and specifications provided with this power tool. Failure to follow
all instructions listed below may result in electric shock, fire and/or
seriousinjury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE.
The term “power tool” in the warnings refers to your mains-operated (corded)
power tool or battery-operated (cordless) powertool.

DeWalt DCS777T2-QW Specifications

General

Brand	DeWalt
Model	DCS777T2-QW
Category	Saw
Language	English
