ENGLISH
8
Installing Accessories (Fig.G)
NOTE: Ensure accessories are securely in place prior touse.
• Slide accessories onto the nozzle
10
.
• For longer reach, attach extension
11
or hose
12
to
thenozzle.
• Accessories may also be attached to the end of the hose
orextension.
Extension: Reach farther to clean
overhead, under objects, and
out‑of‑reachplaces.
Removing Dust Bowl (Fig.D)
1. Remove the dust bowl
2
by pressing the dust bowl
release button
3
and pulling the dust bowl down
andout.
Installing Dust Bowl (Fig. E)
NOTE: It is very important that the filter is correctly
positioned beforeuse.
1. Line up the rib
17
on the motor housing
18
with the
slot
19
of the dust bowl.
2. Install the dust bowl onto the unit and listen for an
audible click. Ensure the dust bowl is secured in place
beforeusing.
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start‑up can causeinjury.
Wall Mounting
Some DEWALT chargers are designed to be wall mountable
or to sit upright on a table or work surface. If wall mounting,
locate the charger within reach of an electrical outlet, and
away from a corner or other obstructions which may impede
air flow. Use the back of the charger as a template for the
location of the mounting screws on the wall. Mount the
charger securely using drywall screws (purchased separately)
at least 1” (25.4mm) long, with a screw head diameter of
0.28–0.35” (7–9mm), screwed into wood to an optimal
depth leaving approximately 7/32” (5.5 mm) of the screw
exposed. Align the slots on the back of the charger with the
exposed screws and fully engage them in theslots.
SAVE THESE INSTRUCTIONS FOR
FUTURE USE
will turn on automatically when the battery pack needs to
becooled.
Never operate the charger if the fan does not operate
properly or if ventilation slots are blocked. Do not permit
foreign objects to enter the interior of thecharger.
Electronic Protection System
Li‑Ion tools are designed with an Electronic Protection
System that will protect the battery pack against overloading,
overheating or deep discharge. The tool will automatically
turn off and the battery pack will need to berecharged.
Important Charging Notes
1. Longest life and best performance can be obtained if
the battery pack is charged when the air temperature
is between 65°F – 75°F (18° C– 24°C). DO NOT charge
when the battery pack is below +40°F (+4.5°C), or
above +104°F (+40°C). This is important and will
prevent serious damage to the batterypack.
2. The charger and battery pack may become warm to the
touch while charging. This is a normal condition, and
does not indicate a problem. To facilitate the cooling of
the battery pack after use, avoid placing the charger or
battery pack in a warm environment such as in a metal
shed or an uninsulatedtrailer.
3. If the battery pack does not charge properly:
a. Check operation of receptacle by plugging in a lamp
or other appliance;
b. Check to see if receptacle is connected to a light
switch which turns power off when you turn out
thelights;
c. If charging problems persist, take the tool, battery
pack and charger to your local servicecenter.
4. You may charge a partially used pack whenever you
desire with no adverse effect on the batterypack.
Charger Cleaning Instructions

WARNING:Shock hazard. Disconnectthe charger from
the AC outlet before cleaning. Dirt and grease may be
removed from the exterior of the charger using a cloth
or soft non‑metallic brush. Do not use water or any
cleaningsolutions.
Belt Hook (Fig.F)

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments oraccessories.

WARNING: To reduce the risk of serious personal
injury, DO NOT suspend tool overhead or suspend
objects from the belt hook. ONLY hang tool’s belt hook
from a workbelt.

WARNING: To reduce the risk of serious personal
injury, ensure the screw holding the belt hook issecure.
IMPORTANT: When attaching or replacing the belt hook,
use only the belt hook screw
9
that is provided. Be sure to
securely tighten thescrew.
Installing Belt Hook
1. Insert the screw part way into the belt hook.
2. Slide the belt hook into place.
3. Fully tighten the screw. Ensure it is securely tighten.
4. To remove the belt hook, remove the screw and slide the
belt hook out.
NOTE: The belt hook
8
can be be attached to either side of
the tool using only the screw provided, to accommodate left‑
or right‑handed users. If the hook is not desired at all, it can
be removed from thetool.
