11
ENGLISH
OPERATION
Instructions for Use
WARNING: To reduce the risk of injury. After
completing assembly and before each use, ensure
all bolts and nuts are properly tightened and all
mechanisms operate properly.
WARNING: To reduce the risk of injury, keep both
hands on handle and the right foot on the extension
leg when raising and lowering the stand. The stand
has gas assist lifting and may raise unexpectedly
when lever is released.
WARNING: To reduce the risk of personal injury,
never release the activating lever when the rolling
mitre saw stand is in vertical position (Fig. T). The
spring loaded mechanism is under tension and can
open unexpectedly, with high force.
Refer to To Raise and Lower the Stand under Assembly to
adjust the stand to the desired height.
To Extend the Extension Work Supports
(Fig. A)
1. Turn the horizontal lock knob
7
counterclockwise.
2. Slide the work support extension arm
9
out or in,
depending on the length of the workpiece.
3. Tighten the horizontal lock knob.
4. Repeat with the other side.
To Adjust Extension Work Support Height
(Fig. A)
1. Turn the vertical lock knob
6
.
2. Adjust the work support
10
up or down to the desired
height.
3. Tighten the vertical lock knob.
4. Repeat with the other extension work support.
To Use the Stop Plate (Fig. A)
The rolling mitre saw stand equip with the stop plate
11
. Please
use the stop plate, if continuous cutting operation necessary.
1. Loosen the stop plate lock knob to rotate the stop plate into
avertical position.
2. Tighten the stop plate lock knob.
STORAGE AND TRANSPORTATION (Fig. T)
WARNING: TIPPING HAZARD. The stand may tip
when storing or transporting the stand close to or
in the vertical position. Transport or store the stand
in the horizontal position to reduce the risk of the
stand tipping.
To lower the stand into the storage position, push down on the
red activating lever, lift up on the handle, then exert downward
pressure on the handle.
Refer to Figure T for proper transporting position.
MAINTENANCE
Your DeWALT rolling mitre saw stand has been designed
to operate over along period of time with aminimum of
maintenance. Continuous satisfactory operation depends upon
proper tool care and regular cleaning.
Lubrication
Your power tool requires no additional lubrication.
Cleaning
WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing this procedure.
WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use acloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
Optional Accessories
WARNING: Since accessories, other than those offered
by DeWALT, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only
DeWALT recommended
accessories should be used with this product.
The rolling mitre saw stand is designed to be used in
conjunction with awide variety of
DeWALT mitre saws,
compound mitre saws and sliding compound mitre saws.
